Home > Products > Prefabricated House > adjustable economical prefabricated 3 story house China
adjustable economical prefabricated 3 story house China
- 2 Square Meter / Square Meters per Month
- XINGANG(TIANJIN)
- T/T
- Integrated housing for outdoor residents
- Folding container house/integrated room/ 3000*2460*2510/mm
- Container house
- Container house
- Modular, steel structure plate, container assembly house, two-wing folding house, expansion house, movable board house.
- Apple Luxury House Cabin Outdoor Modern Popular Prefab House Mobile Working House Office Casa Capsula
Product Details
Place of Origin: | Beijing, China | Brand Name: | CDPH | Model Number: | K type prefabricated 3 story house |
Material: | Other, steel sandwich prefabricated 3 story house | Use: | Hotel, House, Other, Office, Shop, Toilet, Villa, Warehouse, Hotel, House, Kiosk,Booth, Office, Sentry Box,Guard House, Shop, Toilet, Villa, Warehouse, Workshop,Plant, prefabricated 3 story house |
Product Description
The detailed information about the k prefabricated 3 story house as follows:
No | Sort | Name | Specification |
1 | Standard | Length | NM+160(N=4,5,6... M is modular, 1M=1820mm) |
2 | Width | NM+160(N=3,4,5... M is modular, 1M=1820mm) | |
3 | Wall Height | 2865mm/3815mm/4765mm | |
4 | Floor beam | C style steel, Q235, painted structure | |
5 | Column | Double C style steel, Q235, painted structure | |
6 | Roof beam | Double slope truss, sealed by the C type steel | |
7 | Roof purlin | C style steel, Q235, painted structure | |
8 | Inclined brace | round steel, material: Q235. Galvanized and Painted | |
9 | Wallboard | 50mm EPS sandwich panel, 0.3mm color steel sheet and 12kg/m3 polystyrene foam density inside. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.663w/.k. | |
10 | Roof board | 50mm EPS sandwich panel, 0.3mm color steel sheet and 12kg/m3 polystyrene foam density inside. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.663w/.k. | |
11 | Door | SIP with steel frame, single door with dimensions of 955*2024mm, furnished with a cylinder lock with 3keys. Doorframe is made of 1.5mm steel, 50mm thick EPS insulation foam. | |
12 | Window | PVC , white color, with dimensions of 1750*950mm, glazed with glass in a thickness of 5mm, two bay sliding, supplied with fly screen. | |
13 | Option | Ceiling | Ceiling of mineral wool acoustic panel, or Ceiling of aluminium panel |
14 | Elevated floor | Steel structure with 14mm plywood | |
15 | Decorative floor | PVC, laminated or ceramic tile | |
16 | Drainage system | Provided plan, design and construction | |
17 | Electric system | Provided plan, design and construction | |
18 | Structure | Bearing load | 50kg/m2 |
19 | Wind pressure: | 0.45KN/M2 | |
20 | Fire proof | B2 grade | |
21 | Resistant temperature | -20 to 50 | |
19 | The resistant earthquake grade | 7 fission activate. |
