kit homes, China house supply, living room
Kit homes ZB is one of our patent house model. The size and layout can be designed as per customers’ requirements and local climate. When delivery, it is knock-down to save space. Based on bolts connection without welding work, it could be assembled and disassembled easily and six common workers can finish 50m2 in 8 hours according to instruction and CD.
The detailed information as follow:
No. |
Sort |
Name |
Specification |
1 |
Specification |
length |
No limited |
2 |
Width |
Less than 11m |
|
3 |
Wall height |
2600mm/2800mm |
|
4 |
Clear height |
2600mm/2800mm |
|
5 |
Roof slope |
15° |
|
6 |
Standard accessory |
Wall board |
75mm thickness double color-steel sandwich panel with polystyrene foam inside. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.546w/ m².k. |
7 |
False ceiling |
75mm thickness double color-steel sandwich panel with polystyrene foam inside. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.546w/ m².k. |
|
8 |
Roof board |
color steel corrugated sheet, 0.5mm thickness |
|
9 |
Outside door |
Security door, single door with dimensions of 900*2100mm, furnished with a handle lock with 3keys. Doorframe is made of 1.2mm steel, and door is made of 0.7 mm steel, 90mm thick rock wool insulation foam. |
|
10 |
Inside door |
SIP, single door with dimensions of 750*2000mm, furnished with a cylinder lock with 3keys. Doorframe is made of aluminum, 50mm thick EPS insulation foam. |
|
11 |
Window(W-1) |
PVC, white color, with dimensions of 1200*1200mm, glazed with glass in a thickness of 5mm, two bay fixed, and two bay sliding, supplied with fly screen. |
|
12 |
Window(W-2) |
PVC, white color, with dimensions 500*500mm, glazed with glass in a thickness of 5mm, casement opening, supplied with fly screen. |
|
13 |
Channel |
Galvanized Steel Plain Sheet press moulding Material: Q235. Painted |
|
14 |
Post |
Square steel tube Material: Q235. Painted |
|
15 |
Purline |
Square steel tube Material: Q235. Painted |
|
16 |
Roof truss |
Square steel tube Material: Q235. Painted |
|
17 |
Decoration and connection |
color steel sheet, 0.35mm thickness |
|
18 |
Option |
Decorative floor |
PVC, laminated or ceramic tile |
19 |
Drainage system |
Provided plan, design and construction |
|
20 |
Electric system |
Provided plan, design and construction |
|
21 |
Technical parameter |
Bearing load |
30kg/m2 |
22 |
Wind pressure: |
0.45KN/M2 |
|
23 |
Fire proof |
B2 grade |
|
24 |
Resistant temperature |
-20 ºC to 50ºC |
