New Product 4ch/8ch/16ch DVR,16ch h 264 Digital Video Recorder

Shenzhen Xingkean Electronic Technology Co., Ltd.
New Product 4ch/8ch/16ch DVR,16ch h 264 Digital Video Recorder thumbnail-1
New Product 4ch/8ch/16ch DVR,16ch h 264 Digital Video Recorder photo-1
US$ 50 - 55 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
XKA
Model Number:
7816
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name XKA
Model Number 7816

Specifications

16ch h 264 digital video recorder
1.Embedded LINUX system
2.Built-in free DDNS
3. Hisilicon Chipset
4.CE cetificate

 16ch h 264 digital video recorder

1.Embedded LINUX system
2.Built-in free DDNS
3. Hisilicon Chipset
4.CE cetificate



New product 4ch/8ch/16ch DVR,16ch h 264 digital video recorder





  Product  specification :



1. Support HDMI/ VGA/ TV simultaneous video output

2. Support 16 / 8 / 4ch simultaneously video record & network transmission, 16ch support 2ch D1,14ch CIF playback, 8ch support 2ch D1+6ch CIF playback, 4ch support 4ch full D1 playback,  and 16 / 8 / 4ch CIF/QCIF sub-code stream

3. H.264 dual-stream video compression

4. Zoom function in both preview and playback

5. Support P2P function and 3G

6. Support UPNP, Build-in free DDNS

7. System supporting a variety of languages menu.

8. Support Multi-code stream technology, and remote surveillance (Iphone, android, symbian, windows and blackberry)

9. Adopted Graphic user operation interface, support USB mouse,wireless mouse,panel and remote operation. Support 1 SATA HDD, support moveable hard-disk back-up.

10. Support varied PTZ control protocol , and embedded web visiting ,support HTTP, SMTP, FTP, DDNS, DHCP, PPPOE, and NAT traversing .

11. Support SMTP,SSL,email alarm, and JPEG capture and email





Parameters :
Model :7816E7808E7804E
Operation systemEmbedded Linux operation system
System resourcesSupport 16 / 8 / 4ch simultaneously video record & network transmission, 16ch support 2ch D1,14ch CIF playback, 8ch support 2ch D1+6ch CIF playback, 4ch support 4ch full D1 playback, and 16 / 8 / 4ch CIF/QCIF sub-code stream
Operation interfaceGraphic Operation interface, Support USB mouse, IR remote, Front panel operation
Video standardPAL,NTSC
Video compressionH.264
Audio compressionG.711
Record modeManual ,timing , alarm , motion detection record
Video searchTime/date ,event , channel , log
Backup modeNetwork backup ,USB backup,inner SATA burner
Video input16ch BNC8ch BNC4ch BNC
Video output1ch BNC,1ch VGA,1ch HDMI
Audio input2ch RCA2ch RCA2ch RCA
Audio output1ch RCA
intercomsupport
Monitoring qualityPAL: 720*576 (D1) ; NTSC:720*480 (D1)
Playback qualityP:352*288(CIF) / 720*576(D1)
N:352*240(CIF) / 720*140(D1)		P:720*576(D1); N:720*480(D1)
Image control6 degree adjustable
Motion detectionEach channel can set up single detection zones, and multistage sensitivity
Image split1/4/9/161/4/91/4
record ratePAL: 1~25fps (adjustable), NTSC:1~30fps (adjustable)
record storageLocal HDD and network
Local playback1~16ch1~8ch1~4ch
Alarm inputNO
Alarm outputNO
PTZ controlRS485
HDD Interface1 SATA
Network1 RJ45 10M/100M adjust-automatically Ethernet interface
USB interface2 USB2.0 high-speed interface
Power supplyDC 12V
Ax dimension280*225*45mm

New product 4ch/8ch/16ch DVR,16ch h 264 digital video recorder

New product 4ch/8ch/16ch DVR,16ch h 264 digital video recorder

New product 4ch/8ch/16ch DVR,16ch h 264 digital video recorder
