Specifications
1.Qualified material2.Flexible design
3.Fast installation
4.Reuse for numerous times
5.Convenient package for shipping
Description
Prefabricated house K Type multi-storey house is a cost-effective prefab house, mainly designed for construction site accommodation and office. Widely used in Asia countries, including China, India, Vietnam, and Thailand, Philippines, Indonesia and etc.
Features:
1, Module: Width and length can be extended by times of 1820mm modular. Flexible design.
2, Fast Installation:Components are standard and fabricated in factory, less site works, quick and easy installation. Eight skilled workers can finish 100 m2 in 8 hours.
3, Reusable:Structures are connected by bolts & nuts, panels plug into channels, house can be knocked down for many times
4, Multi-storey: Can be one, two and storey storeys.
5, Loading: One 40HQ container can load about 250m2without raised floor , or 200m2 with elevated floor.
6, Parameters:Wind load: 0.45KN/ m2, Anti-seismic: 7 , Service life: 5~10years.
No. | Sort | Name | Specification | |
1 | Specification | length | NM+160(N=4,5,6... M is modular, 1M=1820mm) | |
2 | Width | NM+160(N=3,4,5... M is modular, 1M=1820mm) | ||
3 | Wall height | 2-Storey 5720mm | 3-Storey 8570mm | |
4 | Clear height | Ground floor :2425mm First floor :2685mm | Ground floor :2425mm First floor : 2425mm Second floor: 2685mm | |
6 | Standard accessory | Wall board | 50mm EPS sandwich panel | |
7 | Roof board | 50mm EPS sandwich panel | ||
8 | Door | SIP with steel frame, single door with dimensions of 960*2028mm, furnished with a cylinder lock with 3keys. 50mm thick EPS insulation foam. | ||
9 | Window | PVC sliding window ,1735*932mm/1735*482mm two bay sliding, supplied with fly screen. | ||
10 | Base beam | C80 style steel. Painted | ||
11 | Column | Double C80 style steel, Painted | Double C80 style steel, ground floor reinforced. Painted | |
12 | Floor beam | Parallel truss(C80 style steel). Painted | ||
13 | Floor purline | Gable truss(C80 style steel). Galvanized | ||
14 | Roof beam | Gable truss(C60 style steel). Painted | ||
15 | Roof purline | Gable truss(C60 style steel).Galvanized | ||
16 | Inclined brace | round steel, Galvanized | ||
17 | Stair | Steel stair, 1100mm wide. | ||
18 | Tread | Press steel board 2.5mm | ||
19 | Floor stab | 15mm plywood | ||
20 | Option | False ceiling | Waterproof gypsum board or others | |
22 | Decorative floor | PVC, laminated wood floor or ceramic tile | ||
23 | Drainage system | Provided plan, design and construction | ||
24 | Electric system | Provided plan, design and construction | ||
25 | Technical parameter | Roof Bearing load | 50kg/m2 | |
| Floor Bearing load | 200kg/m2 | ||
26 | Wind resistance: | 10 degree | ||
27 | Fire proof | B2 grade | ||
28 | Resistant temperature | -20°Cto 40°C | ||
29 | The resistant earthquake grade | 7 degree seismic intensity | ||
