TDA-810 High Speed Crank Shedding Air Jet Loom
>This series of looms due to its high rigid frame structure, suitable for weaving high density,
high fine fabric.A letoff, takeup and each detection unit are used in electronic control thus reduce
the stop block,the mechanical stop and warp or weft weaving defects such as short rates to improve
the quality of production.
>Frame and beam rigidity is enhanced, the machine has good stability, beating -up mechanism further optimization.Structure more reasonable, can use four or six Linkage
Beating-up connecting rod.
>The six connecting rod beatingup can prolong the time for opening of warp and weft, more suitable
for wide loom weaving fabric, broaden the scope of weaving loom.
>The opening mechanism of this type of crank optional: opening,cam,electronic dobby, jacquard,
With electronic letoff and takeup, variable density of weft knitting; warp stop, double weft electronic
length measuring, electronic weft storage, selvage yarn breaking detection,edge detection by
catching weft yarn, electronic control make the operation more humane.
>Its structure is reasonable: the further optimization of beam structure change the warp tension
sensing more sensitive.
>After the tension roller bracket is installed in the outside of the frame, which is convenient fo installation and repair.
>Can set all kinds of weaving parameters.
Main specifications of this plastic net woven machine:
| Rate | up to 1235m/min, depending on fabric types |
| Reed space | 150, 170, 190, 230, 280, 340cm |
| Weft |
Short fiber-7 to 60 tex ( 80 to 10 Ne, need additional device if below 10Ne) Long fiber-5 to 44 tex (40 to 400den) |
| The main transmission | AC starting torque motor direct starting, slow forward and reverse running |
| beating-up | bilateral four connecting rod, the six connecting rod beating up |
| weft stop | double weft detection |
| Shedding | crank, cam, electronic dobby, jacquard |
| take up | electronical |
| Let -off | electronic let-of |
| weft supply | single colr, two color, four- color mixed free weft |
| Stops | 6 lines of electronic stopping device |
| Sevage | leno (rough and plain) |
| Electronic control | using programmable computer controller as the core |
| Lubrication | the big gear, let-off, take- up gear box with the oil bath type lubrication, the other by forced centralized oil supply mode |
a,Pls do not hesitate to make an inquiry, you will get response within 24 hours,
b,We are 24 hours online. Customer can contact us through tradmanager,whatsapp,skype E-mail.etc.
c.With the support from our experienced design and technique team,
d,We have the professianl sales team, will you the best solution with our great enthusiasm.
Why Choose Our Company?
A: History:Tongda Textile machinery Group was establish in 1952.Now have more than 60 years old history.
B: Main Products:Tongda Group specializes in design, manufacturing, and marketing of a wide range of Textile machinery, it has seven branch companies, mainly produces ring spinning frame,roving frame,weaving machine(water Jet loom/Air jet loom/rapier Loom),warping machine, quilting machine and nonwoven machine.
C:Product /Quality Guarantee: All the Machine have 1 year Quality Guarantee.
D:After Sale Serivice: We are work online 24 hours. If you have any questions about our machine you can contact us.
E: Reputation:
(1) Q: Are you a manufacturer or Trade Company?
A: We are a professional manufacturer holding our own International Trade Department, for that
we can better understand customer's needs and offer a reasonable price.
(2) Q: Are you available for on-the-spot invitation?
A: We do welcome our new and old friends come here to have a visitation.
Besides, we would send you our exposition and relative information to promote a face-to-face meeting if you'd like to.
(3) Q: Is the price offered changeable?
A: We offer reasonable price for every client, and the price is changeable according to purchasing amount.
(4) Q: How about the quality?
A:The main subassembly and raw materials are all supplied by large companies. Key parts are research and developed by our own staff. Professional assembly line work and strict quality test system can ensure your high quality requirement.
(5) Q: How's the after-sale service?
A: We offer engineers available to service overseas under merchandiser's supervision and translation.
