EXLAS 1410 Laser Machine

Specifications

1.Laser-type: Hermetic and detached CO2 laser tube
2.Laser-power: 80W (100W 150w,or 180W for option)
3.Cooling Mode: Circulating-water-cooling
4.Power Adjustment: 0-100% controlling, no segment and adjusting by software
5.Machine Control and Drive: Speedy DSP controlling, stepper motor
6.Max Engraving Speed: 48000mm/min
7.Max Cutting Speed: 500mm/min(when cutting 10mm thick of acrylic)
8.Repeating Location: 0.01mm
9.Minimum Character: Chinese character 1.5mm, crisscross-row 1mm
10.Max Power: 1800W
11.Adjustable Up-down Distance of Laser Head: 40mm
12.Working Travel Area: 1400x1000mm, 1450mm width with infinity material-feeding
13.Table Area: 1450x1050mm
14.Up-down Range of Working Table: Mechanical 260mm
15.Working Voltage: AC220V 50Hz
16.Working Environment: Temperature: 0-45oC, Humidity: 5%-95%, and congeal-water removed
17.Controlling Software Language: English, Simplified Chinese, Traditional Chinese and procuring of multi-languages
18.Dictate Format: *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.ai,*las, Support AutoCAD,CoreDraw direct outputting
19.Body Dimension: (LxWxH) 2020x1480x1300mm
20.Packaging Dimension: (LxWxH) 2120x1700x1450mm
21.Gross Weight: 487kg
22.Machine Color: Customizable
23.Optional Equipment:  Rotary attachment
                                       Motorized up-down table
                                       Water-cooling unit
                                       Red-light position
                                       Vacuum table
                                       DSP Off-line operation with usb flash

24.Guarantee & Aftersales Service:

Laser tube 10,000 hours' working time

Guarantee: One year from the date of commissioning

24-hour technical support by email or calling

User-friendly English manual for machine using and maintaining
