Help CenterPrefabricated Office Building, EPS Sandwich Panel; Modular Building for Office
Related Products
-
Green and Cheap Prefabricated House, Military Barrack Camp House,Well-designed High-qualified Beautiful HouseUS$ 80 - 90MOQ: 60 Square Meters -
Precast House as OfficeUS$ 80 - 120MOQ: 150 Square Meters
-
High Quality Prefabricated Building for SaleUS$ 50 - 120MOQ: 160 Square Meters
-
Steel Prefabricated Houses, Quick Assembly Houses,prefab Concrete HousesUS$ 50 - 75MOQ: 1 Unit
-
2015 Modern Prefabricated House, Made in China, Low Cost for Labour Living,site OfficeUS$ 50 - 85MOQ: 1 Unit
Specifications
1.Qualified material2.Flexible design
3.Fast installation
4.Reuse for numerous times
5.Convenient package for shipping
Modular building for office K type is a flexible modular house. The size and layout can be designed as per customers’ requirements and local climate. When delivery, it is knock-down to save space. Based on bolts connection without welding work, it could be assembled and disassembled easily and six common workers can finish 50m2 in 8 hours according to instruction and CD.
The detailed information as follows:
No | Sort | Name | Specification |
1 | Standard | Length | NM+160(N=4,5,6... M is modular, 1M=1820mm) |
2 | Width | NM+160(N=3,4,5,6 M is modular, 1M=1820mm) | |
3 | Wall Height | 2865mm/3815mm/4765mm | |
4 | Floor beam | C style steel, Q235, painted structure | |
5 | Column | Double C style steel, Q235, painted structure | |
6 | Roof beam | Double slope truss, sealed by the C type steel | |
7 | Roof purlin | C style steel, Q235, painted structure | |
8 | Inclined brace | round steel, material: Q235. Galvanized and Painted | |
9 | Wallboard | 50mm EPS sandwich panel, 0.3mm color steel sheet and 12kg/m3 polystyrene foam density inside. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.663w/.k. | |
10 | Roof board | 50mm EPS sandwich panel, 0.3mm color steel sheet and 12kg/m3 polystyrene foam density inside. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.663w/.k. | |
11 | Door | SIP with steel frame, single door with dimensions of 955*2024mm, furnished with a cylinder lock with 3keys. Doorframe is made of 1.5mm steel, 50mm thick EPS insulation foam. | |
12 | Window | PVC , white color, with dimensions of 1750*950mm, glazed with glass in a thickness of 5mm, two bay sliding, supplied with fly screen. | |
13 | Option | Ceiling | Ceiling of mineral wool acoustic panel, or Ceiling of aluminium panel |
14 | Elevated floor | Steel structure with 14mm plywood | |
15 | Decorative floor | PVC, laminated or ceramic tile | |
16 | Drainage system | Provided plan, design and construction | |
17 | Electric system | Provided plan, design and construction | |
18 | Structure | Bearing load | 50kg/m2 |
19 | Wind pressure: | 0.45KN/M2 | |
20 | Fire proof | B2 grade | |
21 | Resistant temperature | -20 to 50 | |
19 | The resistant earthquake grade | 7 fission activate |
