Specifications
XYZ Plasma cutting machine can cut any conductive metal in high efficiency.And it is applicable in automobile, ship, etc.
XYZ Plasma cutting machine
The character of Plasma cutting machine.
1 advanced DSP control system, work without computer, design friendly.
2 integral structure ensure the stability of the machine running speed up to 22m/min, cutting speed up to 15m/min.
3 superior quality plasma power, Japanese THK liner track, ensure work piece cutting vertical in high efficiency.
4 can cut aluminium, steel and any other conductive metal in high efficiency.
5 applicable in industrial areas as automobile making, ship production, accessories of electric appliances, any various covers of mechanical and electric production and plank materials
Processing.
6 with original software
The data for cutting thickness and speed of plasma works on difference materials are as follows:
Steel Max. cutting thickness: 8mm
Iron Max. cutting thickness:15mm
Aluminium Max. cutting thickness: 7mm
Cooper Max. cutting thickness: 8mm
Working size | 1300x2500 |
Motion speed | 20000-25000mm/min |
Processing speed | 200-20000mm/min |
Dictate format | HPGL, G CODE |
Motor | Stepper motor |
Angle cut | 1.8 degree |
Holding torque | 2.35 n.m/24kg.cm |
Plasma generator power supply | 380V 50/60Hz |
Machine body power supply | 220V 50/60Hz |
X,Y drive system | Rack and pinion drive |
Z axis | Screw drive Pitch=5mm |
Control system | DSP System |
Software | English Artgrave Software |
Plasma generate | Made in China(not fixed) |
Optional | US Hypertormance(better effect) |
