Specifications
CNC router XYZ-P-12181.T slot table
2.high speed and accuracy
3.CE certificate
4.ball screw transmission
CNC Router XYZ-P-1218
CNC Router XYZ -CAM 1218(Steel tube table with 1200x1800x120mm) ball screw transmission, DSP system, delta servo, 1.5kw air cooled spindle, 1.5kw Delta inverter, Tool sensor, software.
Machine Model | XYZ-P-1218 Advertising CNC Router |
Working Arae | 1200x1800x120mm |
Spindle Motor | 1.5KW inverter-driven spindle motor HSD air cooled |
Working Mode | delta servo |
Control System | DSP(128MB) or PCIMC control system |
Drive Mechanism | German imported ball screw for x, y, z axis |
Table Surface | T-slot extrusions |
Frame | Cast Aluminum |
Motion Positioning Accuracy | Approx 0.02/300mm |
Repositioning Accuracy | Approx 0.01mm |
Max Motion Speed | 7000mm/mim |
Max Engraving Speed | 5000mm/min |
Rotating Speed of Spindle | 2,4000rmp |
Engraving Tool | 3.175mm,4mm,6.00mm |
Dictate Format | G code,*.u00,*.mmg,*.plt, HPGL/NC |
Operating Voltage | AC220V/50Hz |
Software | Type3 original with Dongle or Wentai/ARTCAM/CAXA |
Packing Size | 2300x1400x1500mm |
Net Weight | 470kg |
Gross Weight | 510kg |
Guarantee | One year from the date of commissioning |
Optional Parts | Dust Collecting System Mist Sprayer &Flume DSP system w/Portable Control Pad(128MB) |
The machine has the characteristic of big rigid, high speed and precision. It is widely used to process various advertisement plates, bill plates, breastplate, constructions model, acrylilc, sucking plastic mould making, wooden handicraft, etc. It is also suitable to engrave different metal or nonmetallic materials such as iron, copper, aluminum, plastic plate, woody plate, and so on.
