Specifications
woodworking CNC Router is widely used in process for single lines, milling, 3D cutting and engraving.Detailed Product Description
XYZ-P-1325ATC CNC Machine
1.Italy 3.8KW/8.0KW HSD ATC spindle
2.Yaskawa Servo System
3.LNC-510i/SYNTEC Control System
NO. |
Items |
Functional Index |
Parameter |
Option |
1 |
Working area |
X |
1500mm |
< =2000mm |
Y |
3000mm |
< =5500mm |
||
Z |
200mm |
< =500mm |
||
2 |
Table size |
|
1400x2900mm |
|
3 |
Precision |
Working precision |
0.04mm |
|
Repositioning accuracy |
0.05mm |
|
||
4 |
Transmission |
Table structure |
Vacuum table |
T-Slot vacuum table |
Transmission way of X,Y,Z. |
X, Y with HIWIN Linear rail, Z with ball screw. |
|
||
5 |
Speed |
MAX travelling speed |
45000mm/min |
|
MAXI working speed |
20000mm/min |
|
||
6 |
Spindle |
Spindle power |
HSD 3.8KW/8.0 KW |
|
Spindle speed |
0-24000r/min |
|
||
7 |
Drive |
|
Yasakawa/Delta servo |
|
8 |
Working voltage |
|
AC380V/50Hz |
AC380V/60Hz |
9 |
Command Code |
|
G code |
|
10 |
Operating system |
|
Syntec/LNC-510i |
|
11 |
Net weight |
|
1600Kg |
|
12 |
Gross weight |
|
2350Kg |
|
