Help CenterMulti-function Eco-friendly Portable Cabin For Temporary Camp Office and Accommodation
Related Products
-
Movable Office With Sandwich PanelUS$ 3,500 - 4,500MOQ: 4 Sets -
Foldable House Made in ChinaUS$ 3,500 - 4,500MOQ: 4 Sets
-
20 Foot Flat Pack Container HomeUS$ 3,000 - 3,800MOQ: 4 Sets
-
Flat Pack 20ft Container HouseUS$ 3,500 - 4,500MOQ: 4 Sets
-
High End Flat Pack Container HomeUS$ 3,000 - 3,800MOQ: 4 Sets
Specifications
1.Flexible combination2.Portable cabine, convenient moving
3.Quick erection
4.5~10 times recycle
5.Steel strong frame
Galvanized structure portable cabin. Good anti-rust ability and long endurable time.
Can be delivered directly as flat packs, Save renting shipping containers fee..
Can be transported as a whole between sites, save disassembling and reassembling troublesome.
Easy installation, Save labor cost.
Recycle use, Save each project’s accommodation cost.
The detailed information as follows:
No. |
Sort |
Name |
Specification |
||
1 |
Specification |
length |
6055mm |
||
2 |
Width |
2435mm |
|||
3 |
Wall height |
2790mm |
|||
4 |
weight |
1800KG |
|||
6 |
Standard accessory |
Wall |
75mm EPS sandwich panel, 0.4mm color steel sheet and 15kg/m3 glass wool density inside. |
||
7 |
Roof |
Outside is 0.5mm color steel as the surface, middle is 75mm glass wool insulation. Inside is 9mm melamine board. Permitted live loading:1.5KN/m² |
|||
8 |
Base |
External wainscot is 0.3mm galvanized steel sheet metal, and insulation is glass wool. The supporting material is 19mm cement fiber board and the inside decoration is 2mm rubber flooring. Permitted loading: 3.0KN/m2 |
|||
9 |
Door |
Steel door, single door with dimension of 850*2000mm, furnished with lock. |
|||
10 |
Window |
1) PVC sliding window, white color, with dimensions of 800*1100mm; Supplied with fly screen. 2) PVC sliding window, white color, size is 800*500mm. Supplied with fly screen. |
|||
11 |
Post |
Galvanized steel, material: Q345-Q235, 3mm thickness. Connection part is M12 high strength bolt. |
|||
12 |
Option |
Drainage system |
Provided plan, design and construction |
||
13 |
Electric system |
Provided plan, design and construction |
|||
15 |
Technical parameter |
Resistant temperature |
-20°Cto 50°C |
|
|
16 |
Wind load |
0.6KN/m2 |
|
||
17 |
The resistant earthquake grade |
7fission activate. |
|
||
