Specifications
Movable, expandableKnock down
High quality
Furnished and ready for use
Container house Specification
Galvanized structure. Good anti-rust ability and long endurable time.
Can be delivered directly as flat packs, avoid container demurrage charge.
Can be transported as a whole between sites by truck, crane or forklift transportation.
Can be disassembling and reassembling, recycle use.
Can be max 3 storey, length & width is expandable through flexible combination.
The detailed information as follows:
No. |
Sort |
Name |
Specification |
||
1 |
Specification |
length |
6055mm |
||
2 |
Width |
2435mm |
|||
3 |
Wall height |
2790mm |
|||
4 |
weight |
2000KGS |
|||
6 |
Standard accessory |
Wall |
Option 1: 75mm EPS sandwich panel, 0.4mm color steel sheet and 15kg/m3 EPS inside; Option 2: 75mm EPS sandwich panel, 0.4mm color steel sheet and 60kg/m3 glasswool inside; |
||
7 |
Roof |
Outside is 0.5mm color steel as the surface, middle is 75mm glass wool insulation. Inside is 9mm melamine board. Permitted live loading:1.5KN/m² |
|||
8 |
Base |
External wainscot is 0.3mm galvanized steel sheet metal, and insulation is 100mm glass wool. The supporting material is 19mm cement board and the inside decoration is 2mm rubber plastic flooring. Permitted loading: 3.0KN/m2 |
|||
9 |
Door |
SIP door, single door with dimension of 800*200mm, furnished with lock. |
|||
10 |
Window |
1) PVC sliding window, white color, with dimensions of 800*1100mm; Supplied with fly screen. 2) PVC sliding window for toilet, white color, size is 800*500mm. Supplied with fly screen. |
|||
11 |
Post |
Galvanized steel, material: Q345-Q235, 3mm thickness. Connection part is M12 high strength bolt. |
|||
12 |
Option |
Drainage system |
Provided plan, design and construction |
||
13 |
Electric system |
Provided plan, design and construction |
|||
15 |
Technical parameter |
Resistant temperature |
-20°Cto 50°C |
|
|
16 |
Wind load |
11 grade |
|
||
17 |
The resistant earthquake grade |
7fission activate. |
|
||
