Help CenterDiscount Price CNC Router Machine For Aluminum Copper Wood ZK-6090 600*900MM With Dust Collector To Keep Clean
Related Products
-
ZK-6060 PCB Carving Machine for Sale Jinan Zhuoke 600*600mmUS$ 2,000 - 4,000MOQ: 1 Set -
Working Table Moving Top Sale Jinan Zhuoke PCB Engraver Cutter Machine ZK-6060 600*600mmUS$ 2,000 - 4,000MOQ: 1 Set
-
Professional PCB Cutting Machine With Computer Controller ZK-6060 600*600mmUS$ 2,000 - 4,000MOQ: 1 Set
-
Top Popular Split Available PCB Engraving Machine With Computer Controller ZK-6060 600*600mmUS$ 2,000 - 4,000MOQ: 1 Set
-
Top Sale Jinan Zhuoke Metal PCB Cnc Router With Computer Controlling System ZK-6060 600*600mmUS$ 2,000 - 4,000MOQ: 1 Set
Product Application
Applicable Industries:
Good at in processing all kinds of small workpiece, widely uesd in advertising signs, badges, logo, mould construction equipment, mould products, industrial mold, etc.
Applicable Materials:
Suitable for all kinds od metal, such as copper, aluminum, iron, stell, stainless steel, alloy, also the acrylic, wood, MDF, double color board, stone, jade, ect.
Main Features
1.Body small, tight, machine body and gantry whole cast iron or aluminum, stable, no deformation, little shock, moving stability.
2.Imported high quality ball screw, precision segmentation, to achieve the high precision engraving.
3.Low noise 1.5kw water cooling spindle, high rotated speed(24000rpm), can realize only diameter 0.1mm tools engraving on the hardness terials.
4.Auto tool calibration help you to set the tools, not break the tool noise, ensuring the workpiece high precision processing.
5.Water cooling system for the metal materials, cooling the cools, avoiding the high temperature breaking tools.
6.High precision gear transmission rotary axis solves the problem for the cylinder processing.
7.Optional control system, NcStudio/DSP/Mach3, high stability, high effciency, easy to learn.
8.Continuing working after the break point/power failure, lower the rejection rate.
9.Good software compatibility, can compatible with the Artcam/Type3/Ucancam/JDPaint such CADCAM software, 2D/3D processing, more convenient to using.
Technical Data:
Working size:600*900*120 mm
Wokring table: Aircraft aluminum T slot
Spindle motor: 1.5 kw water cooling
Collet type: ER 11/20
Suitable tools diameter: 3.175/4/6/8/10/12.7 mm
Voltage: AC 220 V ,50/60 Hz single phase
Spindle speed:0-24000 rpm/min
Auto tool calibration: For Z-axis
Empty traveling speed:0-8000mm/min
Technical Data:
Driving mode:stepper motor
Control system: PCI NcStudio
Carving instructions:G code *U00*mmg *plt HPGL
Design software: Artcam 2008
Engraving speed: 0-6000 mm/min
Machine accuracy: 0.05 mm
Resetting accuracy:0.02 mm
Diagonal error:0.5mm
Technical Data:
Guide way: Linear round guide rail (Hiwin linear square guide rail is optional)
Transmission: Ball screw
Technical Data:
Accessories:
water pumps
Dust collector
PCI card
Tools
Brush&Spanner
Jigs
Data line
CD
Pre-Sales Service
1.Offer us a call, even cooperate with us or not, you may get unexpected harvest.
2.We could discuss the future development of this line together accroding to many years' experience in selling and producing which could help to enlarge the profits and improvement for both of us.Studying customers' requirement carefully.
3.we could help clients to choose the best suitable machine andalso will offer you the relative samples and suggestions promptly and consinderately to customer's production scale and technical requirement.
After-Sales Service
1, We will deliver the machine as soon as possible, We will deliver the nomal models within 5 days receiveing the orders for abnormal models, the delivery time is at most 15 days.
2, Our technicians will provide on-site servie to customers in China, We will supply the whole day on-line service to foreign customers, According to foreign customer's requirement, we will arrange techinians go abroad to install or maintenance the machines,.
3, Within the warranty period and the machine parts were damaged under normal using condition, we will offer new parts for the free
4, We will offer software upfrades for free.
5, After the expiry of warranty, we can renewal of the contract, which will enjoy the same service that during the warranty period.
6, The company will research the staffs service attitude aperiodicalty to improve the service satisfaction.
