Auto Tool Changing Wood CNC Router Changing 3 Spindles With Original NcStudio System Dust Collector ZK-1325
Applicable Industries
Woodworking industry: cupboard door, craft wooden door, solid wood door, panel engraving and cutting, stereo
wave board processing, panel furniture, painting door, paintfree door, screen, craft windows working, furniture
milling and engraving, wooden musical instrument 3D engraving
Other industry
Advertising industry: advertising signs, acrylic cutting, logo making, plastic molding, a variety of advertising and
decorative products making
Machine features
1. The machine body structure adopt high quality steel pipe welding, with geometry frame structure, strong bearing
strength, processing jitter low.
2. Machine 3 axis adopt Taiwan linear square guide rail, double class four row ball slider, operating smoothly, high
accuracy, durable.
3. XY axis adopt super-modulus gear pinion with high speed and accuracy. At the same time, Z axis use imported ball screw, high precision,
lower knives accurately
4. Adopt highspeed step motor and drivers. Two motors for Y axis make machine operating more sable and higher accuracy.
5. Using the air cylinder, changing, 3 spindles to change the 3 kinds tools, middle one is 3.0kw, mainly used for cutting, another two is 2.2kw, mainly used for engraving,
6 Dust collector, helping to suck the dust, milling dust, keeping the machine clean.
7. Original NcStudio control system, high stability, high efficiency, easy to learn.
8 Continuing working after the break point/power failure, lower the rejection rate.
9.Good software compatibility, can compatible with the Artcam/Type3/Ucancam/JDPaint such CAD/CAM
software, 2D/3D processing, more convenient to using.
Technical parameters
Items |
Description |
Optional items |
Certificate |
CE |
|
Effective working area |
1300(X)mm*2500(Y)mm*200(Z)mm |
|
Materials |
Square steel tube machine bed, cast iron gantry |
|
Guide rail |
Linear square guide rail |
Linear round guide rail |
Transmission |
Rack and pinion transmission |
|
Driving mode |
Stepper motor |
|
Spindle motor |
3.0kw +2.2kw+2.2kwwater cooling |
Or 5.5kw or air cooling |
Spindle speed |
0-24000rpm/min |
|
Empty traveling speed |
0-60000mm/min |
|
Engraving speed |
0-25000mm/min |
|
Machine accuracy |
0.03mm |
|
Control system |
NcStudio | Or DSP offlineor MACH 3 |
Carving Instructions |
G code *Uoo *mmg *plt HPGL |
|
Compatible software |
Artcam, Type 3, Ucancam,etc |
|
Also have other models
ZK-3030 300*300mm ZK-4040 400*400mm ZK-6060 600*600mm
ZK-6090 600*900mm ZK-9015 900*1500mm ZK-1212 1200*1200mm
ZK-1215 1200*1500mm ZK-1218 1200*1800mm ZK-1224 1200*2400mm
ZK-1530 1500*3000mm ZK-2030 2000*3000mm
Packing: 11.50CBM, 1300kg
Shipping: EXW/FOB/CIF/DDU/DDP... according to your need
For a formal quotation, pls let us know:
You will use the cnc router for what kind of materials?
Engraving or cutting?
What size working area you need?
Main procedure for ordering the cnc router
1. Confirm the machine suitable configuration for you
2. We send you the proforma invoice with the final price, our bank information
3.You take the bank slip to bank to make the deposit
4. We start to produce the machine for you, about 3-10 working days, after finished, will send you pictures and videos for checking
5. The ship departure, we send you the copy of bill of lading and other documents, if no problem, you pay us balance, we will send you all the documents.
I would like to send you more information& working videos, just feel free to contact us! ( Miss. Amiee Zhang)
