CH-WH070 good design and quality sandwich panel prefabricated house for sale
Description of the sandwich panel prefabricated house for sale
The sandwich panel prefabricated house is widely used in all over the world. As it is made of steel structure which is a new type of building structure system, which is formed by the main steel framework linking up H section, Z section and U section steel components, roof and walls using a variety of panels and other components such as windows, doors, cranes, etc. And the sandwich panel prefabricated house is low cost and can be conveniently moved to anywhere. The sandwich panel prefabricated house is flexible, energy saving and environmental friendly and so on. At present, the sandwich panel prefabricated house is more and more popular.
The material of the sandwich panel prefabricated house for sale
Wall structure frame of sandwich panel prefabricated house |
“U” shape steel frame |
||
Concrete frame |
|||
Exterior wall of sandwich panel prefabricated house |
Light weight eps cement |
||
wall panel |
|||
Exterior wall decorative board |
Imitation brick texture Wall |
||
Interior wall of sandwich panel prefabricated house |
Light weight eps cement |
||
wall panel |
|||
Interior wall decorative material |
Emulsion Paint, putty powder or tile |
||
Panel used in Kitchen & toilet |
Light weight eps cement wall panel |
||
wall panel |
|||
Corner post of sandwich panel prefabricated house |
Square tube or concrete |
||
Wall Pillar of sandwich panel prefabricated house |
Rectangular tube or concrete |
||
Roof & Ceiling |
Steel roof truss |
“C”steel or steel structure |
|
Roof panel |
Light weight pes cement wall |
||
panel or color steel sandwich panel |
|||
Roof tile |
Strip slate or glazed tile |
||
Ceiling |
PVC panel or Gypsum board |
||
Floor of sandwich panel prefabricated house |
Floor lateral support |
Round steel or concrete |
|
Floor grider |
"H"steel |
||
Floor panel |
Light weight eps cement |
||
wall panel |
|||
Floor decorative board |
Tile or composite wooden |
||
floor panel |
|||
Toilet ground tile |
Tile |
||
Why us about the sandwich panel prefabricated house for sale
1. Modern design
The size, appearance and space layout of our sandwich panel prefabricated house for sale can be designed as per customer’s wish. We can offer you technical advices and make sure your sandwich panel prefabricated house is individual and eye-catching.
2. Mobile, repeated use
Our sandwich panel prefabricated house for sale can be moved easily. You can move it repeatedly and relocate it anywhere you want.
3. Good insulation for heat and sound, good fireproof and waterproof
The adopted sandwich panels of our sandwich panel prefabricated house for sale have a good heat insulation, with thermal conductivity lower than 0.036W/(m×K). The fire resistance is B1 grade and the noise reduction reaches up to 40db. So it can make your prefabricated house safe and comfortable. And thanks to the use of integrated roof and drainage system, our sandwich panel prefabricated house for sale is completely waterproof.
4. Strict quality control system
We have the strict quality control, and unqualified product can’t be loaded. This is the tenet of our factory. We do the strict testing procedures on each sandwich panel prefabricated house before it is loaded, to ensure 100% quality assurance.
5. Long lifespan
The main steel materials of our sandwich panel prefabricated house for sale have been surface treated by high anti-corrosion processing of sand blasting and multi-layer painting. Our sandwich panel prefabricated house for sale can serve you 25 years.
Performance |
roof load |
0.5KN/sqm(can reinforce the structure as required) |
Wind speed |
designing wind speed: 210km/h (Chinese standard) |
|
seismic resistance |
magnitudes 8 |
|
temperature |
suitable temperature.-50°C~+50°C |
About us
Green (Tianjin) Technology Development Co., Ltd. locates in Baodi Jiuyuan Industrial Park with total investment 25 million U.S. dollar. Our company has always been focusing on environment improving, energy saving products, steel further processing products and corresponding all-around services. Our company owns the qualification of Environmental Engineering Contractor ( Grade Ⅲ ), Steel Structure Engineering Contractor ( Grade Ⅲ ). We have passed the authorization and audit of ISO system and possesses more than 20 patents.
The professional design, reasonable price and reliable quality of our sandwich panel prefabricated house for sale will be most attractive. Looking forward to building the long term cooperation with you! Any question, pls don’t be hesitated to contact me!
