CH-WH056 one bedroom prefab house kits china supplier for sale
The description of one bedroom prefab house kits
Cheaper and easier than normal buildings, one bedroom prefab house kits is your best choice to create modern, colorful modular homes. Instead of bricks and concrete used by traditional construction, our one bedroom prefab house kits adopt steel structure as the skeleton and sandwich panel as insulation. What the most exciting thing, is that the appearance and interior space division of the one bedroom prefab house kits can be designed according to customer's requirements. And thanks to the overwhelming superiority of high remoldability, you can freely use your imagination to decorate the one bedroom prefab house kits and you can move and relocate it anywhere you want.
The material of one bedroom prefab house kits
Steel framework |
Top beam frame |
Q235, 5mm galvanized channel steel, color-painted |
Base beam frame | ||
Column | ||
Purlin |
Q235, 4mm rectangle steel pipe |
|
Wall of prefab house kits |
External wall panel |
50/75/100mm PU/EPS/rockwool sandwich pannel |
Internal wall panel | ||
Decorative board |
PVC |
|
Roof & Ceiling |
Roof |
Color-painted steel sheet |
Insulation layer |
50/75/100mm PU/EPS/rockwool sandwich pannel |
|
Ceiling |
PVC panel or Gypsum board |
|
Floor of prefab house kits |
Insulation layer |
50/75/100mm PU/EPS/rockwool sandwich pannel |
Decorative board |
PVC, bamboo plywood or floor leather |
|
Door & Window |
External door |
Sandwich door with aluminum frame/security door |
Inner door |
Sandwich door with aluminum frame/PVC door |
|
Window |
PVC sliding window/Aluminum alloy window, shutter |
|
Optional system |
Drainage system |
16-20mm diameter PVC pipe, |
Provide design and installation | ||
Electric system |
Provide design and installation |
|
Exhaust fan or air exchange hole |
steel or PVC, 250mm*250mm |
Specification of one bedroom prefab house kits
Our one bedroom prefab house kits | ||||
Model |
External Size |
Thickness of |
Internal Size |
Weight |
(L*W*H) |
insulation(mm) |
(L*W*H) |
||
20FT-50 |
5800*2250*2650 |
50 |
5650*2100*2500 |
2000-2500KG |
20FT-75 |
5800*2250*2650 |
75 |
5600*2050*2450 |
|
20FT-100 |
5800*2250*2650 |
100 |
5550*2000*2400 |
|
Our one bedroom prefab house kits | ||||
Model |
External Size |
Thickness of |
Internal Size |
Weight |
(L*W*H) |
insulation(mm) |
(L*W*H) |
||
40FT-50 |
11600*2250*2650 |
50 |
11450*2100*2500 |
4000-4500KG |
40FT-75 |
11600*2438*2896 |
75 |
11400*2050*2450 |
|
40FT-100 |
11600*2438*2896 |
100 |
11350*2000*2400 |
|
The advantage of our one bedroom prefab house kits
1. Safe and durable: The structure of the one bedroom prefab house kits is based on strictly design in working loading, wind load, snow load and seismic and therefore the structure is safe and reliable. Structure is designed to serve more than 25 years.
Performance |
Roof bearing load |
1.5KN/m2 |
Floor bearing load |
3.0KN/m2 |
|
Wind resistance |
12-Level |
|
Seismic resistance |
10-Magnitude |
|
Fire resistance |
B1 Grade |
|
Temperature range |
-40 to 50 oC |
|
Thermal conductivity |
<0.036W/(m×K) |
|
Noise reduction |
40db |
|
Lifespan |
Up to 25 years |
2. Fast assembly and Dismantle: Fast assembly and short construction period, 4 works with 3 hrs can complete one bedroom prefab house kits installation; One bedroom prefab house kits can be without any solid wastes during assembly and dis-assembly process or any damages to the site environment. Also, it’s zero loss to the main components and thus can be repeated to use.
3. Excellent performance: Excellent materials of the one bedroom prefab house kits can be recycled, economic and environment friendly materials; have excellent functions of insulation, wind proof, seismic resist, vapor proof, water proof, electricity leak proof, burglar proof and water draining.
4. Heat insulation and sound proof: 75mm thick double layer color steel sheet with glass wool insulation for the wall, capable of excellent heat preservation, vapor proof and hear insulation functions. Heat insulation coefficient≤0.031/m.k and meantime with sound insulation function and comfortable environment.
5. Strict quality control system: We have the strict quality control, and unqualified product can’t be loaded. This is the tenet of our factory. We do the strict testing procedures on each one bedroom prefab house kits before it is loaded, to ensure 100% quality assurance.
About us
Green (Tianjin) Technology Development Co., Ltd. locates in Baodi Jiuyuan Industrial Park with total investment 25 million U.S. dollar. Our company has always been focusing on environment improving, energy saving products, steel further processing products and corresponding all-around services. Our company owns the qualification of Environmental Engineering Contractor (Grade Ⅲ), Steel Structure Engineering Contractor (Grade Ⅲ). We have passed the authorization and audit of ISO system and possess more than 20 patents.
If you are interested inour one bedroom prefab house kits, please feel free to contact with me. Hope we can build long term cooperation and have the fruitful future.
