KB150-7 FR150-7 Motorcycle

Specifications

Focus the lastest design
High performance with powerful engine
Aluminum wheel, black chromed engine, low fuel consumption

• We will deliver what we promise.
• We will be accountable for our performance.
• We will work as a team to deliver the best possible results.
• We will treat our customers and distributors with respect, honesty and professionalism.



KINBO WILL HELP YOUR BUSINESS FASTRAN GROWING !!



Main technical specification:

Loading quantity:	24units/20GP, 50units/40HQ
Dimension ((L×B×H)mm):	2260×845×1110
Carton size: L×W×H:	1900*570*980
Wheel base (mm):	1480
Min.Ground Clearance (mm):	160
Dry Weght:	140kg
Number of Axles:	2
Engine Type:	Single-cylinder, air-cooled, four-stroke
Engine model:	162FMJ
Bore×Stroke:	56.5mm×49.5mm
Displacement:	149ml
Maximum Power:	8.5kw/8000r/min
Maximum Torque:	7.5N.m/7500r/min
Fuel capacity	14L
Clutch:	Manual clutch, Wet multi-plate
Lubrication:	Pressure/ splash
Start:	Kick / Electric start
Brake:	Fr. Disc brake Re. drum brake
Ignition:	C.D.I
Max. Speed (km/h):	95km/h
Economical Fuel Consumption	≤2.1L/100Km
Front Type Size:	100/90-16
Rear Type Size:	120/90-15
