Small Body PIR Motion Detector module
Features and Electrical Specification
Compact size: 24*32 mm
Supply current: DC3V-24V
Current drain :< 0.1mA
Voltage Output: High level signal: 3V, Standby output is 0V
Input 3-24V, Output 3-24V
TTL output: TTL output can be directly connected to micro-controller or logic device
High sensitivity
Delay time: 2S-70min(adjustable)
Operation Temperature: -20-60°C
Infrared sensor: dual element, low noise, high sensitivity
Detecting length:6-8m(adjustable)
Detecting Angle:120°
Light sensor:included(3-10lux adjustable)
Lens information
Lens diameter: 23mm (default), detecting angle≤120 ° , detecting range<8M
Picture:
Logistics:
Corporate Vision:
1.Best service
2.Good quality
3.Competitive price
4.Sufficient supply
Shipping:
1. The items normally will be shipped out within 3 working days after the payment confirmed.
2. It will be shipped by DHL/FedEx /TNT/ UPS /EMS or other special way. Please contact with us and chose the best one.
You should pay attention to this:
3. Any accidents and delays or other issues caused by forwarder, please forgive that we can not take responsibility.
4. Your payment for the shipping cost will be highly appreciated.
Refund & Replacement:
1. One month for return policy from the arrival date.
2. Please simply return to us for replacement or refund, when you find the unperfected quality items or they don’t work well.
3. If the items are defective please notify us within 3 days after arrival.
4. Any items must be returned in their original condition to get a refund or replacement.
Contact information:
Tel : 86-411- 82556766
Fax: 86-411-82556988
Other Policies:
1. About MOQ which depends on your order.
2. About warranty we give one month for refund or replacement.
3. About sample which needs your charge.
4. About inventory which changes everyday and depends on your order.
5. About order process: We will send you a PI (term of shipping, aggregate amount and so on) after receive you parts list.
We also take OEM,ODM orders as your design, if you have any question, feel free to contact us.
