New design 150cc Motorcycle with balance shaft engine

Specifications

Focus the lastest design
High performance with powerful engine
Comfortable for riding with economic fuel consumption

• We will deliver what we promise.
• We will be accountable for our performance.
• We will work as a team to deliver the best possible results.
• We will treat our customers and distributors with respect, honesty and professionalism.



KINBO WILL HELP YOUR BUSINESS FASTRAN GROWING !!



Main technical specification:

150cc / 200cc balance shaft engine

Loading quantity:	32units/20GP  105units/40HQ
Dimension ((L×B×H)mm):	2260×845×1100
Carton size: L×W×H:	1700*460*860
Wheel base (mm):	1350
Min.Ground Clearance (mm):	1350
Dry Weght:	130kg
Number of Axles:	2
Engine:	Single-cylinder, air-cooled, four-stroke
Engine model:	162FMJ
Bore×Stroke:	56.5mm×49.5mm
Displacement:	149ml
Maximum Power:	9.0kw/8500r/min
Maximum Torque:	8.5N.m/7500r/min
Clutch:	Manual clutch, Wet multi-plate
Lubrication:	Pressure/ splash
Start:	Kick / Electric start
Brake:	Fr. Disc brake Re. drum brake
Ignition:	C.D.I
Max. Speed (km/h):	90km/h
Front Type Size:	110/90-16
Rear Type Size:	130/90-15
