100w 120w 150w 200w Bridgelux Led Chipset Driver ul Listed ul Led High Bay Light

Name: 100w 120w 150w 200w Bridgelux Led Chipset Driver ul Listed ul Led High Bay Light
Brand: SYNNO or OEM
SKU: 123012883

US$ 240 - 260 MOQ: 5 Units

Key Specifications

LED Light Source:

Bridgelux

Warranty(Years):

Input Voltage(V):

220

Jiangmen Synno Lighting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Jiangmen

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source Bridgelux

Warranty(Years) 3

Input Voltage(V) 220

Lamp Luminous Efficiency(lm/w) 100

Color Temperature(CCT) Cool White

Working Lifetime(Hour) 50000

Lamp Body Material Aluminum Alloy

IP Rating IP54

Certification CE

Place of Origin Guangdong, China

Brand Name SYNNO or OEM

Model Number SL-HB-H3-150W

100w 120w 150w 200w bridgelux led chipset driver ul listed ul led high bay light

LED Power Consumption	1X150w
System Power Consumption	160w
LED Initial Flux	13000lm (*Pure White 6000K-6500K)
Lamp Maintain Flux (*After the lens and thermal stabilization)	11500lm (*Pure White 6000K-6500K)
Illumination (Enadir) (@ PW6500K,120 degree reflector)	Mount Height= 6M : 101.57 lux Mount Height= 8M : 57.13 lux Mount Height= 10M : 36.57 lux Mount Height= 12M : 25.39 lux
CRI	WW: Ra>60 PW:Ra>70
Light Distribution Curve	Circle Facular
Beam Angle of Reflector	45° / 90 °/120 °
Light Decay	< 15% (20,000 hours)
Input Voltage	AC85V-AC265V, AC277V+ (50Hz-60Hz)
Working Voltage	36VDC
TJ	55 °C ±10 %
Lamp Efficiency	>85%
Power Factor	>0.95
IP Grade	IP54
Dimensions	L34xW27xH21CM (Lamp Body Only) Φ 50cm X H14cm(120° Reflector)
Net Weight	8.0KG±5 %(Lamp Body Only) 0.5KG±5 %(120° Reflector)
Material	Aluminum Alloy + PC
Working Environment	Temp: -40°C ~ 55°C Humid:10%-90%

Features

This product adopts good Aluminum Alloy heat sink,it has superior heat dissipation,exquisite apperance and fine workmanship
This product adopts imported high brightness LED light source.Built-in constant current driver, to ensure energy-saving efficiently and stable work .
No UV radiation emitted; no Mercury; no ballast required.
Recommend to use white and warm white color .150 watt Warm White (2700-3200k),Neutral White (4000-4500k) and Cold White high power integrated LED light source,LED efficiency 90~95LM/W,Color rendering index Ra>76.
Solid-state wide voltage (85~265V/AC)and constant current design with no noise or flickering.
