MDF Auditorium Wall soundproof Acoustic Diffuser and Fabric Acoustic panel
Popular Movable Wooden Hotel Partition
Product introduction:
Moveable partitions are a series of individually operated panels along a track system designed for maximum space planning flexibility. They can be arranged quickly, easily and efficiently.
-----------------------------------------------------------------------------------------------------------------------
Features:
- Top hung system without the need for a floor track
- Retractable top and bottom seals ensure effortless movement of panels
- Combines elegance with robust construction
- Concealed or exposed panel edge profiles
- Numerous panel stacking options for complete flexibility
- Sealed for life roller assemblies provide smooth and silent movement
- The system offers various levels of sound reduction
- Extensive range of surface finishes available
-----------------------------------------------------------------------------------------------------------------------
Model:
Series |
Thickness (mm) |
Applied height (m) |
Width of Intermediate panel (m) |
Acoustical reduction coefficient (db) |
Hanging weight |
#65 |
65 |
2.0~4.5 |
0.6~1.2 |
35 |
30kg/m2 |
#85 |
85 |
3.0~6.8 |
0.6~1.2 |
45 |
35kg/m2 |
#100 |
100 |
5.0~8.0 |
0.6~1.2 |
53 |
45kg/m2 |
#120 |
120 |
7.0~13.0 |
0.6~1.2 |
65 |
65kg/m2 |
Track:
suitable used in:
s, recording rooms, listening rooms, rehearsal rooms and more professinally interspace timbre projects.
2.theaters, indoor gymnasiums, discos, KTV rooms and more performance and entertainment location.
eting rooms, offices, halls, hotels and more sound absorption and secrecy projects.
4.air-port, railways, bus-stops, manufactories, workshops and more noise reduction projects.
the section configuration of special wooden acoustic panel: substrate, felt and surface.
1)substrate(basal material): based on high quality of 12/15/18mm MDF with density of 750kg/m3,
more choices for basal material:HDF, E1 ECO-friendly MDF and Fireproof MDF(B1 grade).
2)feld: acoustic fleece, pasted on the back of the panel, noise reducible and fire resistant(made in CHINA, GERMANY AND FRANCE)
3)surface: available in three different finishes: real wood veneer, printed wood melamine finished and fireproofing surface.
----------------------------------------------------------------------------------------------------------------------------------------
Installation:
1,PREPARING
1)constructing location: keep dry, the temperature should be higher than 10'C, the widest humidity range should confined to 40%-60%
after construction 24 hours before constructing, the location should reach the standards as above.
2)acoustic panels: for the acoustic panels accommodated to the circumstance of constructing, please place the panels in the
constructing location for 48 hours, check up the type, specification and amount of the panels before constructing.
3)keels: fix the keels on the wall flatly according to the plan, the keels should be flat, slick, no rust, no metamorphosis; the
wall must be construct according to the standards, the keels suitable install with acoustic panels, leave smaller than 500mm space
between each wooden keel(smaller than 600mm of light steel keel), install the keels vertically with acoustic panels.
2,FIXING
1)siz of wall: all panels should be installed in accordance with the manufacturers recommendations.
2)cutting: all necessary hardware and accessories for a complete job installation are to be furnished by the contractor.
3)install the acoustic panels: the installation of acoustic panels should be carried out in a sequence from the left to the right,
from upside to downside, the panels are cut to fit on site, traditional woodworking tools are suitable for cutting the panels, if
panels are cut using a fine tooth table saw the panels should be cut face up to avoid scratching and at a much slower speed to
avoid any tearout or chipping.
4)fix on keel:
1)wooden keel fixing using nails, staples or screws into prefixed timber battens on the walls via the tongue and groove joint.
2)also can fixing by: Light Steel Keel(size: 18*26*3000mm, use clip(size: 45*38mm) to fix.(needs 2.1m of keel and 17 clips per m2)
Hot sale products
Leeyin Group is strict on every step of production to ensure the best quality.We provide full-scale quality management system and passed ISO9001:2008 Not long after the was established.
In March 2006, Guangzhou Liyin Building Material Co., Ltd was established in Guangzhou city,with the factory Foshan Blue Ocean Architectural Acoustic Material Co., Ltd in Foshan. Our group has launched eight series of wooden acoustic panel, Fabric acoustic panel, Wood-wool acoustic panel, Polyester fiber acoustic panel, Suspended absorber, Diffuser, Wooden dry-hang panel, Vibration damping & soundproofing materials, which sums up to 200 items. All our products are of high quality and have achieved great acceptance by both domestict and oversea markets.
1.We are very glad that the customer give us some suggestions for price and products.
2.We will sincerely provide the best service and production for you .
3.The material of our products are mostly made from local resource by hand.
4.The product process also match the traditional and modern technic.
5.Our products have been exported US, RUSSIA, UK, GREMANY and other countries and regions.
Elegant design,reliable quality control , short delivery let us have high reputation from our clients.
1. Are you a trading company or a factory ?
Our company was established in Guangzhou city, with the factory in Foshan. We are a manufacturer engaged in acoustic material for more than 8 years. Welcome to pay a visit to our factory.
2.How can you guarantee the quality?
We have a modern management system. Take strict selection for upstream suppliers to insure the basic material to be good quality. And we pay more attention to production technology and staff training, so that the defective rate is less than 1% of each products, save cost at the production line. When the productions are ready, they would be sent to the package workshop, put in carton with foam between each panel to avoid the friction and damage.
3.Do you accept customization?
Yes, we can support our clients with OEM, so that it can be easier to open the local market and build a long-term partnership between us.
4.Can you offer sample?
Yes, we can offer standard samples for free, and customization is available.
5.How long is the lead time.
Normally 10-25 days upon receiving the deposit, base on the quantity 1,500 SQM
6.Can you assist for installation?
Yes, we can arrange to assist in installation if needed.
7.Do you have CE certificate?
Yes, we do. We have shipped many goods to European countries.
8.What are the factors of influencing the NRC?
Perforation rate, gap between the wall and panel, the density and thickness of the glass wool, etc. All these factors will effect NRC.
9.What's the difference between normal panel and acoustic panel?
Acoustic panel also called soundproof panel which is designed according to the law of soundproofing. There are mainly three functions of acoustic panel. Sound absorbing, sound diffusing and sound insulation, with respect to a specified sound source and receptor: increasing the distance between source and receiver, using acoustic panel to reflect or absorb the energy of the sound waves, using damping structures such as acoustic panel, or using active antinoise sound generators.
10.How about the capacity of your factory?
500000sqm per year.
11.How to pay ?
you can pay by western union or T/T.Cash will be ok if we do business face to face .
