Home > Products > Solid and bulk material level detection > Rotating paddle silo level sensor
Rotating paddle silo level sensor
- 5000 Set / Sets per Month
- China
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | KD | |
| Model Number | KDSS86F |
Standard exporting carton, 2 PCS in 1 inner box, 36 PCS in an outer box
Product Description
Rotating paddle silo level sensor
Features:
- High precision, robust Level controller
- High quality motor;
- Operate reliable;
- Four position sensitivity adjustable, applied widely;
- Clutch device protect motor;
- Double shaft sealing, protection class: IP65
- Stainless-steel rotary probe and paddle
- Test strictly;
- High/low temperature type, extension length, all kinds of paddle, optional
- Measure level for powdery solid material:
*Cereal *animal feed *wood chip *Plastic * sand *granular material *Rubber *agglomerate charge *cement
Specifications:
Power source: | 110VAC, 220VAC, 50/60HZ |
Power Consumption: | 3W |
Contact capacity: | SPDF 220VAC/5A 220VAC/3A |
Rotary speed: | 1RPM |
Insulation voltage: | AC1500V/min |
Torque: | 30~100kg.cm |
Specific gravity: | >=0.5 g/cm3 |
Connection: | screw probe 1"PF / 3/4"PF Flange JIS 2-1/2*5Kg/cm3 |
Drawing:
All available model:
Model | Desc. |
KDSS86: | standard screw connect |
KDSS86F: | standard flange connect |
KDSS86M: | shaft protective tube type |
KDSS86G: | shaft length adjustable type |
KDSS86FT: | flange type hi-temp. |
KDSS86MT: | shaft protective tube type |
KDSS86GT: | hi-temp. shaft length adjustable type |
Wiring panel:
Maucfacturing facilities:
Company Profile
Guangdong Kaidi Energy Technology Co. Ltd, is leading supplier of process control instruments and safety switches, and specialized in R&D, manufacture, marketing and service of point level detection, belt conveyor protection. Main products include: belt sway switch, pull cord switch, level switch. We have extensive experience in the field of energy, metallurgy, electric power, power, automation, electronics, chemical, government, municipal, education, water-treatment, pharmaceutical equipment, machinery, and other industries, We achieve High-precision and High-quality products with sophisticated equipments, advanced testing instruments, professional talents and modern management. Our management and technology team value brand, efficiency and quality, and carry out the managing standard of the ISO9001 Quality Control System, take integrity and quality as the principle. High purity products, Short delivery time and Best service.
