Vibration fork level Switch
- 5000 Set / Sets per Month
- China
- T/T Credit Card
Product Details
Place of Origin: | Guangdong, China | Brand Name: | KAIDI | Model Number: | KFLS10 |
Packaging Details
Each in foamed plastic and inner cartom, and packed in Carton outbox
Product Description
Specifications
1. Anti-vibration,reliability and sensitivity.2. Temperatures up to 150 C
3. No moving parts, no maintenance
4. Small size
- Vibrating (Turning) fork water level switch is based on the intelligent technology of computer and analog circuit.
- Compared with traditional instruments, this new instrument overcomes false actions due to environment factors and dramatically improves anti-vibration, reliability and sensitivity.
- At the same time, it can be adjusted online by situation changing in field. 485 bus can carry out central control. As a patent product, this instrument can offer better function for customers.
- Fine grained free flowing solids including very low density and pneumatically conveyed media, powders, plastic chips, cement, sand, sugar, food grains
- For detecting level of granular solid material submerged in liquids of low viscosity, like sand, gravel, plastic chips under water.
- For applications requiring the processing of different type of material in the same vessel.
Power supply: | AC 220V 50Hz or DC 24V |
Output: | SPDT. or PNP.NPN. |
Temp: | fork -30°C~150°C, the meter -30°C~70°C |
Pressure: | <2Mpa |
Power: | <1W |
Density: | >0.6g/cm³ |
Action point: | Dip vertically 25mm into water |
Vibrating time: | ~3secs.response time.~1 sec |
Output: | 1a1b.AC 220V/3A,DC 30V/3A |
Backlash: | ~3mm Delay: 1.50S |
Connection: | Customized |
Cable: | M12X1.5. OD.6.8mm. |
Material: | Aluminum Alloy/SUS304.SUS316L |
Weather Proof: | IP65 |
