Y83-2500 Hydraulic Briquette Machine With CE

FOB Price

US$ 2,000 - 100,000 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	Unite Top
Model Number	Y83-1800	Condition	New
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Product Name

Y83-2500 hydraulic briquette machine with CE

Applications:

Y83 series of briquetting presses are applied to compress metal sawdust (steel, cast iron, aluminum & copper) into high density briquettes to reduce burning loss during smelting. Cast iron briquettes can substitute pig iron as raw material.

Features:

Hydraulic drive, operation stable, no vibration, safe & reliable.
Simple foundation needed.
PLC control, manual & automatic operation optional.

Technical Specifications:

Model	Cyl. Force	Press Mould	Pressure on	Briquet Size	Briquet Weight	Production Rate	Motor
	(kN)	(mm)	Briquet (MPa)	(mm)	(kg)	(KG/HR)	(kW)
Y83-250A	2000+550	Φ110×180	263	Φ110×(50-70)	2.6-3.7	800-900	18.5
		Φ120×180	221	Φ120×(50-70)	2.9-4.1
Y83-250B	2000+550	Φ110×300	263	Φ110×(70-100)	3.6-5.2	1000-1100	22
		Φ120×300	221	Φ120×(70-100)	4.1-5.9
Y83-315A	2850+550	Φ120×180	278	Φ120×(50-70)	3.1-4.5	900-1100	22
		Φ140×180	204	Φ140×(50-70)	3.6-5.1
Y83-315B	2850+550	Φ120×300	278	Φ120×(70-100)	4.4-6.3	1100-1200	30

Y83-400	3450+550	Φ125×300	326	Φ125×(70-100)	5-7.2	1200-1300	30/37
		Φ140×300	260	Φ140×(70-100)	5.9-8.5
Y83-500A	4900+600	Φ150×300	283	Φ150×(70-100)	6.9-9.9	1300-1800	30/45
		Φ180×300	196	Φ180×(70-100)	8.9-12.8
Y83-500B	4900+600	Φ150×300	283	Φ150×(70-100)	6.9-9.9	1300-1800	45
		Φ180×300	196	Φ180×(70-100)	8.9-12.8
Y83-400W	3450+550	Φ140×(300+200)	260	Φ140×(70-100)	5.9-8.5	2000-3000	3×22

Prouducts show

Packaging & Shipping

nude packing or wooden cases

Our company now has annual output of more than 3,000 sets hydraulic equipment, and has a high quality, young and innovative capability of research team, our company designates special products developed based on the needs of users.
