Specifications
STC-1000 digital temperature controller for freezer/refrigerator digital temperature controller,defrostig,fan,refrigeration
Our company
We're the manufacturer and has been customizing digital thermometer and temperature controller for heating and refrigeration equipment manufacturers since 2004.
The products are UL, CE, CQC, TUV , ISO9001:2000 and RoHS approved.
Technical supply free, one year guarantee and whole life long maintenance.
STC-1000 digital temperature controller for freezer/
refrigerator digital temperature controller
Specification
STC-1000 Main functions and features:
1,Multi-control mode among refrigeration,defrost,fan,etc.
2,User menu and administrator menu can be set separately. Not only convenient for user operation,
but also left enough space for the adjustment of high-level management.
3,Differential control mode, and the resolution of temperature display is 0.1
4,Multi-protection and alarm mode optional
5,COPYKEY function
Main technical parameters
STC-1000 Temperature control:
Switch the modes between cool and heat automaticly ;Control temperature by setting the temperature setting value and the difference value;Temperature calibration; Refrigerating control output delay protection; Alarm when temperature exceeds temperature limit or when sensor error.
Specification and Size:
1.Front panel size:75(L)×34.5(W)(mm)
2.Mounting size:71(L)×29(W)(mm)
3.Product size:75(L)×34.5(W)×85(D)(mm)
4.sensor length:2m(include the probe)
Technical Parameters:
1. Temperature measuring range:-50°C~99°C
2. Resolution:0.1°C
3. Accuracy:±1°C(-50°C~70°C)
4. Sensor error delay:1 minute
5. Power supply:220VAC±10%,(110VAC),50/60Hz
6. Power consumption:<3W
7. Sensor:NTC sensor (1PC)
8. Relay contact capacity:Cool(10A/250VAC);Heat(10A/250VAC)
our factory
payment
T/T, MoneyGram, PayPal, Western Union, Cash, Escrow
To find your target product
Thank you for your interest to our product.
* If you feel confused that our items do not meet your require, contact us, tell us your require, we can do it.
* If you do not really understand the specification, contact us, tell us, we can explain it.
* Any questions, any details, let us communicate.
Service
1. Professional technical team, technical supply free,
2. Customized options
3. Custom product
4. one year guarantee and whole life long maintenance.
There is always a suitable one for you!
U-Controll Electric, your best choice!!
We look forward to hear from you!!!
Nice and lucky day!
