Infiniti/Challenger stable printer FY-3278N
1. Equipped with 8 SPT 510-50PL print heads.
2. AC servo motor is used to run the carriage quicker and more stable.
3. Individual color cleaning minimizes the waste of the ink;
4. 3 way intelligent heater (pre/print/post) helps bring more vivid output;
5. Edge feather function can blur the pass line and feather pass edge
Specification:
Model | FY-3278N | |
Printhead | Drop on demand Piezo Head(SPT510-50PL) | |
Number of Printhead | 4 or 8 Heads | |
Max Print Width | 3,200mm(125.98inch) | |
Print Speed | 161m2/hr Draft 2Pass | |
114m2/hr Standard 3Pass | ||
91m2/hr Quality 3Pass | ||
71m2/hr Compensation 3Pass | ||
Media | Max width | 3,300mm(129.92'inch) |
Max Weight | Roll media:80kg | |
Type | Frontlit,Backlit,Vinyl,Polyester,Window Film,Mesh, Leather,Backlit Film,Blue Back Paper.. | |
Thickness | 4.5mm (Max.) | |
Heating System | 3 way intelligent heater | |
Auto Media Feeding& | Equipped | |
Ink | Type | Solvent C,M,Y,K ink. |
Capacity | 1L or 5L per Color Main Tank | |
Auto Cleaning System | Positive Pressure Cleaning,Anti-Clogging Flash Function&Capping System | |
Print Interface | USB 2.0 | |
Power Specification | AC 220V/230V 50Hz/60Hz 2300W | |
Operational Environment | Temperature20°C-28°C Humidity40%-60% | |
Compatible RIP Software | Photoprint, UltraPrint,Topaz, Wasatch, Caldera, Maintop | |
Dimension & Weight | Machine | L4,600mm X W970mm X H1,290mm 405kg |
Package | L4,930mm X W1140mm X H1,620mm 692kg | |
Pictures to reference :
Front side of FY-3278N, with strong heavy body.
Cooling fan to keep the printing drying faster , make the picture more vivid and clear .
the wide table make in aluminium , keep printing stable and quiet.
The printer will come with the sofeware , and operate instruction book for you .
Logo of FY3278N Infiniti , and emergency switch .
AC motor make the running fast and smoothly.
Place for outspent ink .
Inside of the printer box .
Temperature controller botton
Machine always be packed in the safe wooden box to against damage.
We keep stocking all kinds of model printers, you are warm welcomed to our whare house check machines in Guang zhou .
other product:
We supply all kinds of spare parts, including all kinds of brand main board, print head boards, ink tube, print head, ink, etc. Any intersting, please feel free to contact us.
-
Why choose us :
1. The advanced equipment,market-oriented product selectin and considerate service guarantee the quality of product. We will bring not only convenient to you, but also a positive return on investion.
2. Comprehensive color management and profiling services, workflow optimization and customized training are offered. To ensure the machines functional, after-services will be offered.
3. All the top brands spare parts and original accessories keep your business running smoothly.
You are welcomed to be our dealer and grow together with CX-union.Let's gain the biggest mutual benefit!
How to order?
Step 1. Contact with me about the details and product you need.
Step 2. Confirm the order to us, provide the following information, and then we will send you Proforma Invoice (PI) for your reference.
Order Details ( Items and Quantity), Company Name, Contact Person, Address, Telephone, Sea port of destination
Step 3. Send payment T/T in advance and notify us (send Bank Slip to us).
Step 4. We will deliver the goods within 5 working days after receipt of your payment, and keep you informed about the order status.
Balance payment should be paid upon copy of B/L. On receipt of balance payment, we will send you original shipping documents by DHL and let you know the tracking number.
Step 5. Confirm to us upon receipt of order.
