CF3M Stainless Steel Gate Valves Price
US$ 20 - 3,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Gate
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Large Size API300 WCB Cast Steel Bare Shaft Gate ValvesUS$ 130 - 1,300MOQ: 1 Set -
WCB Gate Valve With Electric ActuatorUS$ 120 - 1,200MOQ: 1 Set
-
316L Stainless Steel Metal Seated Gate Valve With SignalUS$ 45 - 3,000MOQ: 1 Piece
-
ANSI Ductile Iron Gate Valve With Epoxy CoatingUS$ 50 - 7,500MOQ: 1 Set
-
Epoxy Coating Ductile Iron Gate ValveUS$ 50 - 7,500MOQ: 1 Set
Standard or Nonstandard
Standard
Structure
Gate
Pressure
Medium Pressure
Power
Manual
Material
Stainless Steel
Temperature of Media
Medium Temperature
Media
Oil
Port Size
2"-36"
Place of Origin
Zhejiang, China
Model Number
Z40W
Brand Name
GL valve
Application
Other, Industry
CF3M Stainless Steel Gate Valves Price
Product Description
CLASS 150~600 CRYOGENIC GATE VALVE
Bolted bonnet, Threaded or welded seat ring
Full bore, OS&Y, Rising stem, Flexible wedge
Pressure relief hole on seat
Stainless trim
ASTM A352 LCB, LC1, LC2, LC3, LC4
A351 CF8, A351 CF8M
Standards compliance
Design and Manufacture: API 600, API 6D, BS1414
Face to face (end to end): ANSI B16.10, API 6D
Flanged connection: 2~24 to ANSI B16.5
Butt welded end: ANSI B16.25
Test and inspection: API 598, API 6D
Material specification
NO. |
Part |
A352 LCB |
A352 LC1 |
A352 LC2 |
A352 LC3 |
A352 LC4 |
A352 CF8 |
01 |
Body |
A352 LCB |
A352 LC1 |
A352 LC2 |
A352 LC3 |
A352 LC4 |
A352 CF8 |
02 |
Seat ring |
A182 F304+STL |
A182 F304+STL |
A182 F304+STL |
A182 F304+STL |
A182 F304+STL |
A182 F304+STL |
03 |
Wedge |
A352 LCB+STL |
A352 LC1+STL |
A352 LC2+STL |
A352 LC3+STL |
A352 LC4+STL |
A352 CF8+STL |
04 |
Stem |
A182 F6a |
A182 F304 |
||||
05 |
Gasket |
Spiral wound/Soft Iron/PTFE |
|||||
06 |
Bolt |
A320 L7 |
A193 B8 |
||||
07 |
Nut |
A193 2H |
A194 8 |
||||
08 |
Back seat |
A182 F6a |
A182 F304+STL |
||||
09 |
Yoke |
A352 LCB |
A352 LC1 |
A352 LC2 |
A352 LC3 |
A352 LC4 |
A352 CF8 |
10 |
Gland Packing |
Graphite |
|||||
11 |
Gland |
A182 F6a |
A182 F6a |
A182 F6a |
A182 F6a |
A182 F6a |
A182 F6a |
12 |
Gland Flange |
A352 LCB |
A352 LC1 |
A352 LC2 |
A352 LC3 |
A352 LC4 |
A352 CF8 |
13 |
Stem nut |
Cu-Aolly,A439 D-2 |
|||||
14 |
Yoke nut |
A194 2H |
|||||
15 |
Handwheel |
Malleable Iron/cast steel/Ductile/Fabricated |
|||||
16 |
Handwheel nut |
A194 2H |
|||||
17 |
Nameplate |
Stainless steel |
|||||
18 |
Pin |
A182 F6a |
|||||
Working temperature |
-46 font |
-60 font |
-73 font |
-101 font |
-115 font |
-196 font |
|
CLASS 150~600 CRYOGENIC GATE VALVE
Class |
Dimensions |
|||||||||||||||||||||
150 |
Size |
inch |
2 |
2-1/2 |
3 |
4 |
6 |
8 |
10 |
12 |
14 |
16 |
18 |
20 |
24 |
26 |
28 |
30 |
32 |
34 |
36 |
|
L-RF |
mm |
178 |
191 |
203 |
229 |
267 |
292 |
330 |
356 |
381 |
406 |
432 |
457 |
508 |
559 |
610 |
610 |
710 |
762 |
71 |
||
L1-BW |
mm |
216 |
241 |
283 |
305 |
403 |
419 |
457 |
502 |
572 |
610 |
660 |
711 |
813 |
864 |
914 |
914 |
965 |
1016 |
1016 |
||
L2-RTJ |
mm |
191 |
203 |
216 |
241 |
279 |
305 |
343 |
368 |
394 |
419 |
445 |
470 |
521 |
559 |
610 |
610 |
710 |
762 |
711 |
||
H |
mm |
540 |
610 |
690 |
780 |
980 |
1180 |
1390 |
1620 |
1810 |
1970 |
2410 |
2410 |
3210 |
3600 |
3880 |
4000 |
4320 |
4310 |
5100 |
||
K |
mm |
200 |
200 |
250 |
600 |
350 |
350 |
400 |
450 |
500 |
500 |
600 |
750 |
750 |
915 |
915 |
915 |
1000 |
1000 |
1000 |
||
Wt |
RF |
kg |
23 |
33 |
40 |
54 |
91 |
132 |
240 |
360 |
45 |
589 |
630 |
780 |
1240 |
1920 |
2432 |
2980 |
3161 |
3450 |
3980 |
|
BW |
kg |
19 |
29 |
37 |
48 |
85 |
126 |
210 |
340 |
465 |
509 |
580 |
740 |
1130 |
1720 |
1810 |
2670 |
2870 |
3250 |
3370 |
||
RTJ |
kg |
24 |
35 |
43 |
57 |
94 |
135 |
205 |
389 |
500 |
593 |
645 |
790 |
1260 |
1950 |
2470 |
3000 |
3200 |
3487 |
4000 |
||
300 |
Size |
inch |
2 |
2-1/2 |
3 |
4 |
6 |
8 |
10 |
12 |
14 |
16 |
18 |
20 |
24 |
26 |
28 |
30 |
32 |
34 |
36 |
|
L-RF |
mm |
216 |
241 |
283 |
305 |
403 |
419 |
457 |
502 |
762 |
838 |
914 |
991 |
1143 |
1245 |
1346 |
1397 |
1524 |
1626 |
1727 |
||
L1-BW |
mm |
|||||||||||||||||||||
L2-RTJ |
mm |
232 |
257 |
298 |
321 |
419 |
435 |
473 |
518 |
778 |
854 |
930 |
1010 |
1165 |
1270 |
1372 |
1422 |
1553 |
1654 |
1756 |
||
H |
mm |
540 |
630 |
690 |
780 |
980 |
1080 |
1390 |
1020 |
1810 |
1970 |
2410 |
2820 |
3200 |
3700 |
4320 |
4510 |
4600 |
4400 |
5100 |
||
K |
mm |
200 |
200 |
250 |
300 |
350 |
350 |
400 |
450 |
500 |
500 |
600 |
750 |
750 |
915 |
915 |
915 |
1000 |
1000 |
1000 |
||
Wt |
RF |
kg |
27 |
49 |
53 |
80 |
152 |
245 |
380 |
610 |
758 |
1100 |
1240 |
1700 |
2380 |
2930 |
3475 |
4310 |
5100 |
4930 |
5240 |
|
RTJ |
kg |
|||||||||||||||||||||
BW |
kg |
24 |
41 |
45 |
64 |
120 |
194 |
310 |
560 |
710 |
980 |
1000 |
1550 |
2120 |
2680 |
3100 |
4100 |
4610 |
4810 |
5000 |
||
Note:
1.ALL of valve part materials comply with ASTM standard.
2.Above material is our normal one.If client has special requirement for it,we choose material as per detailed site condition.
3.More information,please inquiry.
Packaging & Shipping
Our Services
Our Innovation
Quality & Service Our top priority has always been providing our clients with great quality products and superior customer service.
Quick Lead Time We're dedicated to providing the quickest turnaround times and work very hard to ensure that all of your deadlines are met.
Unbeatable Prices We continuously strive to find ways of reducing our production costs, and passing the savings over to you!
Quantity Guarantee Period 12 months from the date of shipment. If the valves determined to be defective, we will replace the defective part without charge .After warranty period, you are requested to pay for the labor charge.
FAQ
Enquiry Notice
The following details should be dated in your enquiry:
1) Size
2) Class
3) Body Material
4) Trim Material (Internal parts)
5) Connection type
6) Operated type
7) Sealing face
8) Temperature
9) Medium
10) Design standard; Connection Standard
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2004
Factory Size
5,000-10,000 square meters
Total Employees
51 - 100 People
