Hydraulic Iron Worker
- any port of China
- T/T
You May Like
-
CNC/NC Hydrualic Shearing/shearing Machine/plate Cutting/guillotine Machine QC11Y-16X3200
-
Hydraulic Press Brake
-
CNC/NC Hydrualic Shearing/sheet Metal Shearing Machine/plate Cutting/swing Beam Machine QC12Y-10X3200
-
Hydraulic Press Brake
-
CNC/NC Hydrualic Shearing/hydraulic Shearing Machine/plate Cutting/swing Beam Machine QC12Y-32X3200
-
Hydraulic Press Brake
Product Details
| Condition | New | CNC or Not | CNC | |
| Power Source | Hydraulic | Place of Origin | Jiangsu, China | |
| Brand Name | HT-metalforming | Model Number | 20 |
Product Description
Specifications
Hydraulic iron workerHydraulic iron worker
model | Q35Y-12 | Q35Y-16 | Q35Y-20 | Q35Y-25 | Q35Y-30 |
Pressure(Ton) | 40 | 66 | 90 | 120 | 165 |
Max.ctting thickness(mm) | 12 | 16 | 20 | 25 | 30 |
/2 Plate strength (N/mm2) | ≤450 | ≤450 | ≤450 | ≤450 | ≤450 |
Cutting angle | 7° | 7° | 8° | 8° | 8° |
Shearing size of one stroke(mm) | 12×220 6×360 | 16×250 8×400 | 20×330 10×480 | 25×330 16×600 | 30×355 6×360 |
() Ram sroke (mm) | 80 | 80 | 80 | 80 | 80 |
( /) Number of srokes(cpm) | 8 | 8 | 8 | 6 | 15 |
( ) throat depth (mm) | 250 | 300 | 355 | 400 | 600 |
Max.punching thickness | 12 | 16 | 20 | 25 | 26 |
Punching diametre (mm) | 20 | 25 | 30 | 35 | 38 |
Max. Punching diametre | 25 | 32 | 40 | 50 | 50 |
punching thicknee (mm) | 8 | 10 | 12 | 15 | 20 |
Power of main motor(KW) | 3 | 4 | 5.5 | 7.5 | 11 |
×× Overall dimensions L×W×H(MM) | 1480×760×1620 | 1640×780×1770 | 1860×800×1900 | 2355×960×2090 | 2680×1040×2300 |
Weight of machine (Kg) | 1230 | 1550 | 1920 | 4670 | 6450 |
