Stainless steel or Ductile iron Bi directional Manual Knife Gate Valve
- Shanghai or Ningbo
- T/T Credit Card
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Gate | |
| Pressure | Low Pressure | Power | Manual | |
| Material | Stainless Steel | Temperature of Media | Low Temperature | |
| Media | Water | Port Size | 2"-16" | |
| Place of Origin | Zhejiang, China | Model Number | GLK0(B)73 | |
| Brand Name | GL Valve | Application | Other, Industry |
Product Description
Stainless steel or Ductile iron Bi directional Manual Knife Gate Valve
1. Product name | Bi directional Manual Knife Gate Valve |
2. Brand name | GL valve |
3. Pressure | PN10&Class150&10K |
4. Size | 2"-16" |
5. Body material | GGG40;CF8,CF8M with solid solution |
6. Gate material | SS304,SS316 with solid solution |
7.Stem material | SS420;SS304,SS316 with solid solution |
8.Seat material | Metal, Viton, NBR,PTFE |
9.Packing material | PTFE& Silicone |
10.Support plate | Carbon steel +epoxy plate |
11.Type | Rising stem or non-rising stem |
12.Operation | Handwheel, bevel gear, DA pneumatic, electric,etc. |
13.MOQ | 1PC |
14.Color | Sample color as attached photos, production color can be customized |
15.Price | Can be negotiated, Please contact us for lastest price. |
16.Packing | Plywood case for knife gate valve |
17.Payment | T/T, L/C, West union 30% before production, balance before shipment. |
18.Quality | Every process is inspected by our QC team |
19.Lead time | 10-60days after receive payment |
20.Sample | Ready samples are available for inspection reference |
Body
Support plates
Knife
Manual Operation
Quality & Service Our top priority has always been providing our clients with great quality products and superior customer service.
Quick Lead Time We're dedicated to providing the quickest turnaround times and work very hard to ensure that all of your deadlines are met.
Unbeatable Prices We continuously strive to find ways of reducing our production costs, and passing the savings over to you!
Quantity Guarantee Period 12 months from the date of shipment. If the valves determined to be defective, we will replace the defective part without charge .After warranty period, you are requested to pay for the labor charge.
Enquiry Notice
The following details should be dated in your enquiry:
1) Size
2) Class
3) Body Material
4) Trim Material (Internal parts)
5) Connection type
6) Operated type
7) Sealing face
8) Temperature
9) Medium
10) Design standard; Connection Standard
