high quality cheap sand ball bead milling machine grinder offset printing ink bead mill
- 30 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A
Product Details
Condition: | New | Type: | Other, bead mill | Product Type: | Other, bead mill for ink, oil paint,coat,pigment,chocolate etc |
Place of Origin: | Jiangsu, China | Brand Name: | Huabao TM | Model Number: | WHD-200 |
Voltage: | 110V-440V,optional | Power(W): | 45000-55000 | Dimension(L*W*H): | 1650*1000*2550mm |
Weight: | 3500kg | Certification: | CE,ISO9001:2008,SGS | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
offset printing ink bead millNSK,ABB,Siemens, best components
China National Research Center
factory built in 1967
CE,ISO
sand mill,bead mill, ball mill.horizontal bead mill,vertical bead mill,sand ball bead mill, offset printing ink bead mill, bead mills. used for chemical,pharmatical,food etc
Established in 1967,is China National special ultra-fine power engineering &researching center and micro-nano fabrication engineering&industrial testing base.
Bead mill series:
1.WST wet dispersing nano bead mill,
2.WSK high viscosity superfine versatile bead mill,
3.WSJ horizontal internal cooling full function bead mill
4.WSZ high viscosity horizontal bead mill,
5.WSS horizontal bead mill,
6.WSH high viscosity vertical bead mill,
7. WHD super fine bead mill,
8.WSV vertical internal cooling bipyramid bead mill.
Note:different model bead mill for different viscosity raw material and for different fineness result.
bead mill ,horizontal bead mill ,vertical bead mill, sand ball bead mill, offset printing ink bead mill for
ink,coat,paint,pigment,pesticides,medicine, dye,cosmetic,sensitive film, foods, electronic paste,
battery industry:cathode materials of the lithium iron phosphate batteries,
digital consumptive materials:digital jet printing ink,
mineral pigment:titanium pigment,calcuim carbonate,ferric oxide,
ceramic materials:alumina oxide,zirconia,silicon carbide,
rare-earth materials:zirconia,indium oxide,cerium oxide,etc,
pharmaceutical preparation,
cosmetic:pearl power.
Above machines are just part of our bead mill machinery,including horizontal bead mill, and vertical bead mill.
Parts of our supplier for bead mill machinery :sand ball bead mill, offset printing ink bead mill
Parts of our clients of bead mill machinery :sand ball bead mill, offset printing ink bead mill
You can get one year warranty for sand ball bead mill machinery,besides,engineer can be sent to your factory to install sand ball bead mill machinery and train your staff, but the buyer should pay for the round air ticket and arrange the hotal,what’s more,we will send some free set of sand ball bead mill machinery spear parts for you to change.best sand ball bead mill , offset printing ink bead mill is supplied to you.
Model | Volume(L) | Medium size(mm) | Motor power(kw) | Capacity Max(L/H) |
WST-5 | 5 | 0.3-0.6 | 11 | -- |
WST-15 | 15 | 0.3-0.6 | 30 | -- |
WST-30 | 30 | 0.4-1.0 | 22 | 180-250 |
WST-50 | 50 | 0.4-1.0 | 30-37 | 400-500 |
WST100 | 100 | 0.4-1.0 | 55 | 1000-1500 |
WSJ-20 | 20 | 0.8-2.0 | 18-22 | 80-130 |
WSJ-30 | 30 | 0.8-2.0 | 22-30 | 100-180 |
WSJ-50 | 50 | 0.8-2.0 | 30-45 | 150-300 |
WSK-80 | 9 | 0.8-2.0 | 22-37 | 80-120 |
WSK120 | 13 | 0.8-2.5 | 37-45 | 120-150 |
WSK180 | 15 | 0.8-2.5 | 45-55 | 180-250 |
WSK280 | 20 | 1.6-2.5 | 55-75 | 280-450 |
WSZ-8 | 8 | 2.0-2.2 | 30-37 | 40-60 |
WSZ-14 | 14 | 2.0-2.2 | 37-45 | 60-90 |
WSZ-25 | 25 | 2.0-2.2 | 55-75 | 100-180 |
WSS-20 | 20 | 0.8-1.6 | 15 | 50-90 |
WSS-30 | 30 | 0.8-1.6 | 18.5 | 80-120 |
WSS-40 | 40 | 0.8-1.6 | 22 | -- |
WSS-50 | 50 | 0.8-1.6 | 30 | 100-150 |
WSS-80 | 80 | 0.8-1.6 | 37 | -- |
WSS100 | 100 | 0.8-1.6 | 45 | -- |
WSS200 | 200 | 0.8-1.6 | 75 | -- |
WSH-14 | 14 | 2.0-2.2 | 30-37 | 60-80 |
WSH-30 | 30 | 2.0-2.2 | 45-55 | 80-120 |
WHD-12 | 1.2 | 0.2-0.8 | 5.5 | 300 max |
WHD100 | 11 | 0.2-0.8 | 22-30 | 1200 max |
WHD200 | 25 | 0.2-1.2 | 45-55 | 3000 max |
WHD400 | 35 | 0.2-1.4 | 90-100 | 6000 max |
WHD800 | 80 | 0.2-1.4 | 250 | 12000 max |
WSV-9.8 | 9.8 | 0.8-2.0 | 22 | 80-110 |
WSV-11 | 11 | 0.8-2.0 | 22 | 90-150 |
WSV-14 | 14 | 0.8-2.0 | 30 | 100-180 |
Note:"--" indicates the data is statistical.
Thank you for reading our website,and welcome to be our agent!
Pls contact your personal technicist Lisa for choosing most suitable sand ball bead mill machine, offset printing ink bead mill,horizontal sand ball bead mill or vertical sand ball bead mill.Our sand ball bead mill are the most advanced with best quality in China. offset printing ink bead mill is supplied to you.
