2015 Hot SVC TND Single Phase 500va To 100kva High Presicion 50Hz 220V Output Automatic AC Voltage Stabilizer
- 5000 Set / Sets per Month
- SB/NB
- T/T Credit Card PayPal
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | AKSDQ | Model Number: | SVC/TND |
Usage: | SVC | Phase: | Single Phase | Current Type: | AC |
Product Description
2015 Hot SVC TND Single Phase 500va To 100kva High Presicion 50Hz 220V Output Autpmatic AC Voltage Stabilizer
Technical Parameter
1. Input Voltage Range: AC150~260V
2. Output Voltage Range: 220V&110V (0.5kva~3kva) ; 220v(above 5kva)
3. Regulation Accuracy: 220V±3%
4. Frequency: 50Hz~60Hz
Advanced Features
1. No-lack dissortion in waveform
2. Reliable performence
3. Support long-term operation
4. Long time no break working
5. Customized function: Time-delay, Under-voltage, Over-voltage
6. Support every single phase equipment
Detail Pictures
Input voltage | 150V-260V |
Output voltage | 220V&110V(0.5kVA-3kVA) 220V(5kVA-30kVA) |
Regulation accuracy | Phase voltage 220v±3% 110v±6% |
Frequency | 50Hz/60Hz |
Overvoltage protection | 246v±4v |
Response time | Within 1 sec. against 10% input voltage deviation |
Environment temperature | -10℃~+40℃ |
Increased temparature | <60℃ |
Waveform disortion | Nolack distortion in waveform |
Overload power factor | 0.8 |
Intensity of electricity resustance | 1500V/1min |
Insulation resistance | >5MΩ |
Model | Outline(mm) | Measurement(cm) | Qty of Package(Pcs) | Weight(kg) |
SVC/TND-500VA | 19*17*13.5 | 44*24.5*35 | 4 | 15 |
SVCTND-1000VA | 22*20.2*16 | 49*28.5*40 | 4 | 20 |
SVC/TND-1500VA | 22*20.2*16 | 49*28.5*40 | 4 | 26 |
SVC/TND-2000VA | 24.5*25.8*19.5 | 60.5*35*25.5 | 2 | 17 |
SVC/TND-3000VA | 23.5*29*23 | 61.5*38.5*29 | 1 | 23 |
SVC/TND-5000VA | 23*31.5*27.5 | 39.5*32*35 | 1 | 13 |
SVC/TND-10K (Ultra low voltage) | 31*34.5*53.5 | 45*42.5*62 | 1 | 33 |
SVC/TND-10K | 31*34.5*53.5 | 45*42.5*62 | 1 | 36 |
SVC/TND-15K | 28*38*77 | 49*40*86.5 | 1 | 52 |
SVC/TND-20K | 32.5*38*77.5 | 49*44.5*88.5 | 1 | 59 |
SVC/TND-30K | 37.5*41.5*78.5 | 53*49*88.5 | 1 | 72 |
Regarding the quality as our life from beginning, our company has gained IOS9001 certification for international qualified quality system and what's more, the products have obtained CB, CCC & CE approval. Our products have passed ISO9001 quality management system certification and ISO14001 environment system certification.
Industry, Agruculture, Transportation, Posts and Telecommunications, Military, Railway, Scientific and Cultural fields of large mechanical and electrical equipment, such as metal processing equipment, elevators and medical equipment, computer room controlled equipment, embroidery and textile equipment, air conditioning, radio, television and household appliances lighting, etc.
Wenzhou Jingkesai Electric Co., Ltd is the branch of China Aksay Electric (Group) Limited. We are a manufacturer of voltage stabilizers, transformers, and regulators with well equipped testing facilities and strong technical force.
Aksay is one of the largest manufacturers and exporters of low voltage electrical equipment in China. Our company founded in 1985 has rich exprience in this line. For these past years, we have made our company larger and modernization, products more outstanding and technolgy higher.
1. What's the payment term?
A. We accept TT,30% deposit and 70% balance agaisnt copy of BL.
2. How's the delivery time ?
A. Usually it will takes about 15-35 days for production, we try to ensure quality, while reasonable to complete the production.
Contact Us
- Jingkesai Electric Co., Ltd.
- Contact nameSusan Li
- Phone86-577-57151155-8555
- AddressFangdouyan Village, Liushi Town, Yueqing
