Help CenterBK-1.5kva Series Machine Tool Control Transformer
Related Products
-
SG Transformer Indoor & Outdoor Three Phase Transformer With Square Box/CaseUS$ 186 - 1,146.8MOQ: 1 Set -
NEW S9 Series Three-phase Oil-immered Transformer Made in ChinaUS$ 105.8 - 3,850.4MOQ: 1 Piece
-
Oil Type Transformer S9 Three Phase TransformerUS$ 260 - 3,850.4MOQ: 1 Piece
-
2015 Hot 380v or 220v Step up Down ac Step Down TransformerUS$ 13.1 - 56.8MOQ: 10 Sets
-
Wenzhou SG Three Phase Power Voltage TransformerUS$ 33.8 - 289.6MOQ: 1 Set
Type |
Rated capacity(VA) |
rated Input Voltage(V) |
Rated output Voltage |
||
Control |
Illumination |
Indication |
|||
BK3-40 |
40 |
220+/-5% |
110 |
24 |
6 |
BK3-63 |
63 |
||||
BK3-100 |
100 |
||||
BK3-160 |
160 |
||||
BK3-250 |
250 |
||||
BK3-400 |
400 |
||||
BK3-630 |
630 |
||||
BK3-1000 |
1000 |
Distribution of capacity for different winding ma be according to the uses request. |
|||
BK3-1600 |
1600 |
||||
BK3-2500 |
2500 |
||||
5.If any special working conditions that are not in line with the above stipulations,user shall negotiate with us,
Main technical characters
1.Input voltage:rated voltage ±10%
2.Output voltage:rated voltage +3%(no load)
3.Efficiency:≥95%
4.Waveform distortion:no additional waveform distortion.
Type |
Rated capacity(VA) |
Uel rated Input Voltage(V) |
Rated output Voltage |
|
||
Control |
Illumination |
Indication |
||||
40 |
220+/-5% |
110 |
24 |
6 |
||
BK3-63 |
63 |
|||||
BK3-100 |
100 |
|||||
BK3-160 |
160 |
|||||
BK3-250 |
250 |
|||||
BK3-400 |
400 |
|||||
BK3-630 |
630 |
|||||
BK3-1000 |
1000 |
Distribution of capacity for different winding ma be according to the uses request. |
|
|||
BK3-1600 |
1600 |
|
||||
BK3-2500 |
2500 |
|
||||
BK Series Machine Tool Control Transformer
Main features:
BK transformer is a transformer 25VA~1KVA a rookie in , is a multi-expert in the innovative products, which used cold-rolled silicon steel sheet core magneticflux leakage of small ,empty small ,the internal resistance of copper with low power consumption, high efficiency. Good flame-retardant, usually used as a tool to control appliances,lighting city council, used the power indicator light.
Working condition
1.Ambient temperature:-15-+40
2.Altitude:<1000m
3.Relative humidity:<90%
4.Environnment exists with out gas,steam,chemical deposition,dust or dirt that will affect transformers insulation seriously,also explosive or corrosive medium is not
Machine Tool Control Transformer
Main features:
BK transformer is a transformer 25VA~1KVA a rookie in , is a multi-expert in the innovative products, which used cold-rolled silicon steel sheet core magneticflux leakage of small ,empty small ,the internal resistance of copper with low power consumption, high efficiency. Good flame-retardant, usually used as a tool to control appliances,lighting city council, used the power indicator light.
Working condition
1.Ambient temperature:-15-+40
2.Altitude:<1000m
3.Relative humidity:<90%
4.Environnment exists with out gas,steam,chemical deposition,dust or dirt that will affect transformers insulation seriously,also explosive or corrosive medium is not allowed.
5.If any special working conditions that are not in line with the above stipulations,user shall negotiate with us,
Main technical characters
1.Input voltage:rated voltage ±10%
2.Output voltage:rated voltage +3%(no load)
3.Efficiency:≥95%
4.Waveform distortion:no additional waveform distortion.
