3 Phase Transformer Indoor or Outdoor Transformer

3 Phase Transformer Indoor or Outdoor Transformer thumbnail-1
3 Phase Transformer Indoor or Outdoor Transformer thumbnail-2
3 Phase Transformer Indoor or Outdoor Transformer thumbnail-3
3 Phase Transformer Indoor or Outdoor Transformer thumbnail-4
3 Phase Transformer Indoor or Outdoor Transformer photo-1
3 Phase Transformer Indoor or Outdoor Transformer photo-2
3 Phase Transformer Indoor or Outdoor Transformer photo-3
3 Phase Transformer Indoor or Outdoor Transformer photo-4
US$ 99.8 - 200.4 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
AKSDQ
Model Number:
SG
Contact Supplier Request Quote Chat Now
Jingkesai Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name AKSDQ
Model Number SG
Usage Power
Phase Three
Coil Structure Toroidal

Wecome

3 phase transformer indoor or outdoor transformer

3 phase transformer indoor or outdoor transformer

Specifications

Three-Phase Dry Transformer Series !

three-phase dry transformer widely uses to AC 50-60Hz, input and output voltage less 500V various three-phase power supply can be designed and made carefully and exquisitely according to user's requirement , including the various input and output voltage, coupling adjustment and position(general in +-5%) , winding capacity distribution, sub-grade single-phase winding disposition, ration , ration current operation and need the outer case or not etc.

Working conditions
1.Ambient temperature: -15°C~+40°C
2.2.Altitude: <1000m
3.3.Relative humidity: <90%
4.Environment exists without gas, steam, chemical deposition, dust or dirt that will affect transformer’s insulation seriously, also explosive or corrosive medium is not allowed
5..If any special working conditions that are not in line with the above stipulations, user shall negotiate with us
Main technical characters
1.Input voltage: 380V 3phase 50HZrated voltage ±10%
2.2.Output voltage:125V 1phase 50HZ rated voltage +5% (no load)
3.Efficiency: ≥95%
4.Waveform distortion: no additional waveform distortion
5.Function: indication of input voltage, output voltage and current.
6.Protection: over-current protection
7.Can operate itself without anybody attending for a long term
8.Insulation resistance: ≥50MΩ
9.Electric strength: no breakdown or flashover phenomenon under power frequency sine voltage of 2000V for 1min
10.Overload capability: for 1min under two times of rated current

3 phase transformer indoor or outdoor transformer3 phase transformer indoor or outdoor transformer3 phase transformer indoor or outdoor transformer3 phase transformer indoor or outdoor transformer

Product Description

3 phase transformer indoor or outdoor transformer

3 phase transformer indoor or outdoor transformer
our advantages

3 phase transformer indoor or outdoor transformer Regarding the quality as our life from beginning, our company has gained IOS9001 certification for international qualified quality system and what's more, the products have obtained CB, CCC&CE approval.Our products have passed ISO9001 quality management system certification and ISO14001 environment system  certification.

applied range

3 phase transformer indoor or outdoor transformer

 Industry, Agruculture, Transportation, Posts and Telecommunications, Military, Railway, Scientific  and Cultural fields of large  mechanical and electrical equipment, such as metal processing equipment, elevators and medical  equipment, computer room computer-controlled equipment, embroidery and textile equipment, air conditioning,    radio, television and household appliances lighting ,etc.

notes

3 phase transformer indoor or outdoor transformer

company profile

3 phase transformer indoor or outdoor transformer

 Wenzhou Jingkesai Electric Co.,Ltd is the branch of China Aksay Electric (Group) Limited. We are a manufacturer of voltage stabilizers, transformers, and regulators with well equipped testing facilities and strong technical force.
 Aksay is one of the largest manufacturers and exporters of low voltage electrical equipment in China. Our company founded in 1985 has rich exprience in this line. For these past years, we have made  our company larger and modernization, products more outstanding and technolgy higher.
3 phase transformer indoor or outdoor transformer
 Unitl now,our company has more than 2000 employees, with over 120 engineers and technicians  among them.  It owns not only high standard production line and checking instrument,  not only the  most  advanced and lead technology, which guarantee our products superior quality and the lowest cost.
Regarding the quality as our life from beginning, our company has gained ISO9001 certificate for  international qualified quality system and what's more,the products have obtained CB,CCC & CE approval. Our company has established long term business connection with clients from all over the world. Enjoying high reputation on the market is a result of excellent quality and first-class services.
certification

3 phase transformer indoor or outdoor transformer

3 phase transformer indoor or outdoor transformer3 phase transformer indoor or outdoor transformer

FAQ

1. What's the payment term?

A. We accept TT,30% deposit and 70% balance agaisnt copy of BL.

  2. How's the delivery time ?

A. Usually it will takes about 15-35 days for production, we try to ensure quality, while reasonable to complete the production.

  3. Tell me the standard of package?
A.  Sturdy wooden export packaging, always.
  4. Could you offer Form A or C/O ?
A. It totally not a problem. We can prepare relative documents to forgin affairs office or other office to apply for this certificate.
  5. Would you accept to use our logo ?
A.If you have good quantity, it absolute no problem to do OEM/ODM.
  6. We want to know month capacity?
A.  We have a monthly production plan and production orders. Monthly production plan to ensure our inventory so that we have enough energy to complete the orders.
  7. Where is your market?
A. Our products are popular in North America, Europe, South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, and so on. We hope you can join us and make mutural benifit from our cooperation.
  8. What kinds of certificate do you have ?
A. CE, RoHS, ISO9001, and test reports.
