Road Wrecker, Breakdown Truck, Tow Truck

Name: Road Wrecker, Breakdown Truck, Tow Truck
Brand: Dongfeng
SKU: 122881275

Negotiable MOQ: 2 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hubei, China

Brand Name:

Dongfeng

Shanghai Longji Construction Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hubei, China

Brand Name Dongfeng

Specifications

roadwrecker(tow truck,breakdowntruck) is refitted with dongfeng EQ1208VJ1 chassis, has delightful appearance, and owns huge powr

Basic Information
Vehicle name	steyer double axle rear		Chassis	ZZ1256M4646F
Outline size(L×W×H) (mm)	9480×2498×3370,3270		Cargo inline size (L×W×H)(mm)	/
Rating mass(kg)	/		Empty mass(Kg)	19150
Full mass(kg)	25000		Emission standard	Euro 2
Engine Information
Model	WD615.67A		Type	/
Power/displacement(KW/ML)	206/9726		Manufacture	WeiChaiPower CO.LTD
Chassis Information
Wheelbase(mm)	4600+1350		Axle load(kg) F/R	Front :/Rear :
Tire	11.00-20		Max speed (km/h)	90
Front overhang(mm)	1958		Rear overhang(mm)	1830
Front track(mm)	1560		Rear track(mm)	1230
Approach angel(°)	15		Departure angle(°)	19
Steering	/		Brake	/
Cabin	Blunt end all-metal upturning (6×4)
Special function
Rating load(Kg)	5655	Max load(kg)			9600
Bracket arm max Length (mm)	1700	Bracket arm companding Length(mm)			3530
Board Size(L×W)(mm)	/	Min slant angle(°)			/
Board working stroke(mm)	2850	Max tow speed (km/h)			40
Winch NO.	2	Rating tow capacity(kg)			10000*2
Steel wire rope lenth(m)	40	Winch speed			5
