Help CenterFully Automatic SMD Chip Counter
Related Products
Specifications
1.acurate and fast2.SMD chip counter
3.Fully automatic counting system
4.pocket check function
Features :
1.Full automactic counting SMD components ,high accuracy count.
2.Easy operate,designed to prevent tape dropping,minimizing risk of damage to tapes.
3.Count forward and reverse ,double-check feature ensures accuracy,built-in memory allows you to preset count quantity.
4.The counter use drafting LCD screen. Small size, light weight, easy to carry
5.Use patent reflector,humanized operation platform.
6.install bar code , convenience electronic component management.
7. optical fiber sensor detect leak ,motor will stop working when detected leak.
Specifications:
Power supply: AC220V (50HZ) or AC110V
Rated power: Approx 3W
Counting capability: 1-50000pcs
Size: 450*180*270mm
Net Weight:7kg Gross weight:9kg
Application :
Universal Products:Suitable for all tape components
Dia. Reel: Suitable for all size
Width of tape: 8,12,16,24,32,44,56,72,88 m
Pitch of tape: 2,4,8,12,16,20,24,28,32,36,40,44,48,52,56mm
Installation :
1.Pannasonic motor , Smooth operation, good stability, high accuracy calculation zerro error.
2.The left and right tray are with steel material ,long use life ,not easy damage.
Machine parts display:
1.Tray
unting device
3.pannasonic motor
4.PLC and key board
fiber sensor detection leak device
Package
