XCMG LW500K Cheap 5t Wheel Loader
US$ 15,000 - 70,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
XCMG
Model Number:
LW500K
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
XCMG 3 Tons Wheel Loader of Wheel Loader With CEUS$ 15,000 - 70,000MOQ: 1 Set -
XCMG LW600K 6ton Wheel Loader SalesUS$ 15,000 - 70,000MOQ: 1 Unit
-
CE & Best Wheel Loader With Chinese Wheel LoaderUS$ 15,000 - 70,000MOQ: 1 Unit
-
12ton XCMG Wheel Loader LW1200K of China Wheel Loader for SaleUS$ 15,000 - 70,000MOQ: 1 Unit
-
XCMG LW500KL of Mini LoaderUS$ 15,000 - 70,000MOQ: 1 Unit
Condition
New
Brand Name
XCMG
Model Number
LW500K
Place of Origin
Shanghai, China
Type
Front Loader
Moving Type
Wheel Loader
Dimension(Long * Breadth * High)
8225*3016*3515mm
Rated Load
5000kg
Certification
CE,ISO
Warranty
One year or 1200 working hour: whichever occurs first
After-sales Service Provided
Engineers available to service machinery overseas
XCMG LW500K cheap 5t wheel loader
5t wheel loader for sale
XCMG 5t wheel loader
china cheap 5t wheel loader
wheel loader 5t
Bivariate assembly, reinforced drive axle made by XCMG.
| Overall Data | Steering System | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Bucket Capacity (m3) | 3 | Type | Hydraulic Load Sensing | ||||||||||||
| Rated Payload(kg) | 5000 | Cylinders-Bore× Stroke(mm) | 2-100×324 | ||||||||||||
| Operating Weight(kg) | 17700 | Steering Pump | Gear Pump | ||||||||||||
| Traction Force(kN) | 155±3 | System Pressure(MPa) | 16 | ||||||||||||
Breakout Force(kN) Max.Dumping Height (mm) | ≥170 3181 | Flow rate(L/m in/rpm) | 176/2200 | ||||||||||||
| Travel speeds (km/h): | Steering Angle | ±35° | |||||||||||||
| I | II | Hydraulic System | |||||||||||||
| Forward | 11.5 | 36 | Lift Cylinders-Bore× Stroke(mm) | 2-180×721 | |||||||||||
| Reverse | 16 | Tilt Cylinder-Bore× Stroke(mm) | 1-200×563 | ||||||||||||
| Engine | WEICHAI WD10G220E21 | Model of Implement Pump | Gear Pump | ||||||||||||
| Rated Power(kw/rpm) | 162/2200 | Flow rate(L/min/rpm) | 220/2200 | ||||||||||||
| Peak Torque(Nm/rpm) | 850/1400-1600 | System Pressure(MPa) | 16 | ||||||||||||
| Starting Voltage(V) | 24 | Pilot Control System Pressure (MPa) | 2.5 | ||||||||||||
| Drive Train | Hydraulic Cycle Time, Rated Load In Bucket(In Second): | ||||||||||||||
| Torque Converter | Single-stage, Duo-turbine, 4-elements | Raise(Loaded) | Dump | Lower(Empty) | Total | ||||||||||
| Torque Ratio | 4 | 6 | 1 | 4 | 11 | ||||||||||
| Transmission | Planetary Power shift Transmission | Electrical System | |||||||||||||
| Gear | 2F/1R | System Voltage(V) | 24 | ||||||||||||
| Pressure of Transmission(MPa) | 1.2-1.5 | Battery (2 in series)(Ah) | 2-120 | ||||||||||||
| Main Reducer | Spiral bevel, 1-stage Reduction | Lamp Voltage(V) | 24 | ||||||||||||
| Final Reducer | Planetary Reduction | Service Refill Capacity | |||||||||||||
| Tire | 23.5-25 L-3 16PR | Fuel Tank(L) | 285 | ||||||||||||
| Brake System | Hydraulic Tank(L) | 285 | |||||||||||||
| Service Brake | Single Circuit Caliper, Dry Brake | Crankshaft(L) | 20 | ||||||||||||
| Setting Pressure (MPa) | 0.78 | Transmission(L) | 45 | ||||||||||||
| Parking Brake | Air Actuated Caliper Brake | Front Axle(L) /Rear Axle(L) | 23/23 | ||||||||||||
| Emergency Brake | Air Actuated Caliper Brake | ||||||||||||||
| Air Conditioning System | |||||||||||||||
| Heating Capacity(W) | 5300(±10%) | ||||||||||||||
| Cooling Capacity(W) | 4500(±10%) | ||||||||||||||
