Truck Crane ( Lifting Capacity 130t )

Name: Truck Crane ( Lifting Capacity 130t )
Brand: CHANGJIANG
SKU: 122879737
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Max. Lifting Load:

130T

Place of Origin:

Sichuan, China

Shanghai Longji Construction Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Max. Lifting Load 130T

Place of Origin Sichuan, China

Brand Name CHANGJIANG

Model Number LT1130

Specifications

Truck Crane ( lifting capacity 130t )

1.1	Boom	Length(m)	13
		Max. rated lifting capacity(t)	130
		Max. lifting height(m)	13.61
	Full extend boom	Length(m)	49
		rated lifting capacity(t)	12
		Max. lifting height(m)	49.1
1.2	Jib	Length(m)	9.5～15
		Max. lifting height(m)	64
1.3	Single line speed (m/min)	Main hoist	0～110
		Aux. hoist	0～58
1.4	Slewing speed(r/min)		0～1.6
1.5	Elevating up/down(s)		110/136
1.6	Boom telescoping extending/retracting(s)		182/125
1.7	Vertical outrigger retracting/extending(s)		≤ 100/50/100
1.8	horizontal outrigger retracting/extending(s)		≤ 60/80
2.	chassis
	Chassis type		QZC5702J
2.1	Drive		12×6
2.2	Engine		1326BTA5.9-C180
		Max. output power	132Kw/2200r/min
		Max. torque	750Nm/1500rpm
			ISXe525　30
		Max. output power	391Kw/1800r/min
		Max. torque	2237Nm/1100～1600rpm
2.3	wheelbase(m)		1.400×2.450×1.400×1.400×1.400
2.4	Wheel span(m)		2.470
2.5	Outrigger type longitudinal x transverse		6.7x7.8
2.6	Max. traveling speed(km/h)		71
2.7	Grade ability		35
2.8	Approach angle(°)		17⁰
2.9	Angle of departure(°)		12°
2.10	Min. turning radius(m)		14.5
2.11	tire type		15.5-20
2.12	Oil wear each hundred kilometer(L)		85
3.	Whole machine
3.1	Max. self-weight in traveling condition(kg)		47500
3.2	Axles load allot KG	I II axle	18800
		III IV V VI axle	28700
3.3	Overall dimensions (LxWxH)		12.700×3.050×3.997
