Help CenterLocking Gas Spring for Medical Bed
Related Products
Gas spring for medical bed
High quality gas spring for medical bed/dental bed/ beauty bed.
This separate the oil from the gas inside the spring ,
so that the damping can be very closely controlled in either compression or extension .
specifications:
Usage: medical bed/dental bed/ beauty bed.
Product description:
Cylinder material: Steel, SS304, SS316
Shaft material: Steel, SS304, SS316
Cylinder finishing: Black ,Silver or other color
Shaft finishing: Chrome/QPQ
Tube diameter:26mm
Rod diameter:10mm Force:350N
stroke length:125mm
Salt spray time: achieving more than 72 hours.
Fatigue test: decay less than 9% after 20,000 cycles.
Service life: at least 50,000 cycles in normal environment.
Working temperature range: –30 °C - +80 °C.
Main Specifications and Dimensions:
| D tube diameter | D rod diameter | M1 thread | M2 thread | F1 Min extention force |
| 18 | 8 | M10*1 | M8/M10*1 | 50-500N |
| 22 | 10 | M10*1 | M8/M10*1 | 100-1000N |
| 26 | 10 | M10*1 | M8/M10*1 | 100-1000N |
| 28 | 10or12 | M10*1 | M8/M10*1 | 200-1500N |
Brief introduction:
gas spring for medical bed.it can play a role in support, cushioning, there is no stop at trip. It used comfortable, convenient installation. Mainly used in aircraft, automobile, engineering machinery, furniture and office supplies industry.
Delivery:
1000 PCS, 7 days.
Shipment: We can accept your appionted forwarder.
gas spring for medical bed/locking gas spring for beauty bed
