Help CenterAdjustable Gas Strut With Release System
Related Products
-
Realse System Rigid Lockable/locking Gas Spring/strutsUS$ 8 - 15MOQ: 100 Pieces -
Hydraulic Gas Spring for Machinery IndustryUS$ 5 - 10MOQ: 100 Pieces
-
Lockable Gas Spring for Bus SeatUS$ 8 - 15MOQ: 100 Pieces
-
Stainless Steel Gas Struts, Gas Spring,for TruckUS$ 2.6 - 8MOQ: 100 Pieces
-
Special End Connector Lockable Gas Spring for MedicalUS$ 2.85 - 5MOQ: 200 Pieces
Specifications
1. Smooth Functioning2. Durability
3. Lightweight
4. Reliable
5. Speed Controlled Operation
Specifications
Rod Diameter (mm) : 10
Cylinder diameter (mm) : 26mm/28mm
stroke (mm) : <=110
L.Max. (mm) : 220
Force (N) : 300-400
Equiped with push-button for release w i t h b o w d e n c a b l e e x i t (cable length : 500 mm)
Cable Length can be customized as per your kind requests
Description
Gas Spring for Auto,Furniture,Machine
1)High quality
2)Competitive pricing
3)With ISO 14001:2004, SGS,ROHS
4)2 Years Warranty
Gas Spring for Auto,Furniture,Machine
1. Spec.:
Extended long: 100~2000mm
Stroke: 10~500mm
Force: 20~3000N
2. Technical parameter for choice
| locking gas spring | |||||||
| diameter piston rod | cylinder | stroke | extended length1** | extension-force | |||
| Φ(mm) | Φ(mm) | (mm) | min.EL2(mm) | F1(N) | |||
| 10 | 22 | 82 | 320.5 | 350N | |||
| 10 | 22 | 100 | 340 | 300N | |||
| 10 | 22 | 120 | 340 | 350N | |||
| 10 | 26 | 100 | 370 | 550N | |||
| 10 | 22 | 100 | 305 | 250N | |||
| 10 | 27 | 82 | 320.5 | 800N | |||
| 10 | 22 | 100 | 340 | 250N | |||
| 10 | 28 | 100 | 345 | 1200N | |||
| 10 | 28 | 60 | 235 | 1000N | |||
3. Usage:
Cabinet, furniture, tool box, machinery, automobile etc.
4. Features:
1) Material: steel
2) Color: silver/black and other options
3) Connector: ball joint/metal eye/clevis and so on
4) Gas: Nitrogen filled inside
5) Color : black,silver,or as clients' request
6) Quality: We can provide fatigue test report. Our products can open and close 100,000 times, Not leak oil; Our paint is passed ROHS test
7) No noise, smooth operation
8) Safe and easy installation
9) Resonable price, excellent quality,delivery soon,good service
10) MOQ: 3000PCS
5. Packing:
1) As standard, 1piece in a plastic bag, then 50-100pcs in a carton
2) Also can be according to customers' request
6. Marking:
1) Is possible to mark your logo as request.
2) No specified, will mark our Logo as standard.
7. Quality:
1) With 100,000 times life
2) Meeting ISO9001 International standard
3) Pass SGS&ROHS certification
8. Warranty:
With one year guarantee except man-made troubles.
9. Delivery Terms:
FOB & CIF&CFR
10. Delivery lead time:
7 working day as normal
11. Shipment:
Goods can be loaded in FCL at our factory or delivered to warehouse in LCL as request.
We can accept your appionted forwarder
12. Advantages of using our Locking gas springs:
- Variable positioning with elastic or rigid locking
- Optimized weight compensation during lifting, lowering, opening, and closing
- Lock into position in the extended or compressed position
- Installation can be orientation-specific or in any orientation, depending on type
- Flat spring characteristic curve for low force increase, even with high forces or large strokes.
- Linear, progressive, or degressive spring characteristic curve
- Mechanical actuation systems, also with an extra small actuation range for easiest operation
- Broad selection of sizes, force variants, and end fittings
- Compact design for installation in the smallest of spaces
- Maintenance-free, even at high loads, with long service life
- High-quality products manufactured in compliance with DIN EN ISO 9001 and the international standard ISO/14001:2004.
Pictures:
Thanks for your kind visit of our Website
Any Interests, pls feel freely to contact:
Ms Ally Zhang
Skype: ally--ty
Mob: 86 +139 2516 4780
