Home > Tools & Hardware > Hardware Accessories > Chain > Buoy Anchor Chain Gold Supplier

Buoy Anchor Chain Gold Supplier

Name: Buoy Anchor Chain Gold Supplier
Brand: XICHANG(buoy chain)
SKU: 122863391
Availability: InStock

Buoy Anchor Chain Gold Supplier thumbnail-1

US$ 0.2 - 1.5 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Hubei, China

Brand Name:

XICHANG(buoy chain)

Model Number:

Dia.8mm-50mm(buoy chain)

Contact Supplier Request Quote Chat Now

Wuhan Jiangnan Anchor Chain Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Wuhan/Shanghai or others

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hubei, China

Brand Name XICHANG(buoy chain)

Model Number Dia.8mm-50mm(buoy chain)

Structure Welded Chain

Function Other, SHIP,VESSEL, Ferry, Boat, MARINE USE

Material Other, Steel

Standard or Nonstandard Standard

Product Description

Buoy chain, Mooring Buoy

Original: China

Packing: Bulk or bags or other required package

Shipping: Wuhan port or others by sea

Chain Diameter: 8mm to 53mm

Chain material: Steel

Finished: Welded Chain

Certificate: CCS, ABS, BV, KR, GL, LR etc

OEM/ODM: avaliable to make as your drawing

V-Cable length accords to marine buoy

Short cable length: 4.5m

Half cable length: 13.7m

Long cable length: 27.5m

Product data

Testing load of studless anchor chain

M S u n i t s

diameter (MM)	BM2		BM3		approx.mass	diameter (MM)	BM2		BM3		approx.mass
					KG/M						KG/M
	break load	proofload	break load	proofload	KG/M		break load	proofload	break load	proofload	KG/M
6	18.6	9.3	-	-	0.78	26	350.8	175.4	488	244	14.67
7	25.2	12.6	-	-	1.03	28	405.7	203.8	566	283	17
8	33	18.5	-	-	1.39	30	457.5	234.2	649.8	324.9	19.5
9	41.8	20.9	-	-	1.73	32	457.5	234.2	649.8	324.9	22.22
10	51	25.8	-	-	2.17	34	599.8	299.9	834.6	417.3	25.08
11	62.4	31.2	-	-	2.63	36	672.3	336.1	935.7	467.8	28.12
12.5	82.6	41.2	-	-	3.39	38	748.7	374.4	1012.5	521.3	31.33
14	101.9	51	-	-	4.25	40	829.1	414.5	1155.2	577.6	34.72
16	132.3	66.2	184.87	92.42	5.56	42	915.3	457.7	1272.6	636.8	38.28
17.5	157.78	78.89	221.1	110.55	6.65	44	999.6	548.8	1527.8	763.9	45.92
19	187.2	93.6	260.64	130.32	7.83	46	999.6	502.7	1397.8	698.9	42.01
20.5	217.27	108.64	303.42	51.7	9.12	48	1195.6	597.8	1663.5	831.7	50
22	250.9	125.4	349.4	74.7	10.5	50	1293.6	648.8	1805	902.5	54.25
24	298.9	149.9	415.8	207.9	12.5

Company introduction

WUHAN JIANGNAN ANCHOR CHAIN specialized in supply Anchor Chain, Chain for Buoy, and Shipping mooring products. We have set cast factory to produce Anchor and Anchor Chain Accesoories as well.

Company has been conducted by Naval Equipment training office in 1998, and esteblished quality control systerm according to National Standard GJB/Z9002-96,GB/T9002. In year 2000, our production have been approved by Chinese New Times Certification Center, which covers from Milltary prodution to civilian shipping production. Company is equiped with No.4, No.5 and No.6 Anchor chain production machine 3 sets, UNT-150,UNT-160 electrical flash welding machine 10 sets, Anchor chain surface polishing machine, 600KN Multi-function material test machine, Intelligentized speed analyser and other inspection facilities in total 28 sets.

Working Shop

All workers in our working shop are very professional on Anchor Chain over 10 years old, they can keep the quality best and produce fast.

M a n u f a c t u r i n g

one kind of package for anchor chain (bags)

Inspection Machines

Product certificate pictures:

ISO9001:2008, CCS, ABS, KR, GL, LR, RS etc

Why Choose us:

1. high quality products

2. competitive price

3. One-stop service

4. fast delivery time
