New power Gasoline engine 40hp RC boat propeller with electric starter

H.P.

40HP

(mm/in)OVERALL LENGTH

1073(42.2)

(mm/in)OVERALL WIDTH

402(15.8)

(mm/in)OVERALL HEIGH

1237(48.7)

(mm/in)TRANSOM HEIGH

ENGINE TYPE

2 stroke

DISPLACEMENT(cc)

703

BORE*STROKE(mm)

80*70

MAX. OUTPUT(hp/kw)

29.4

RPM

4500-5500

STARTING SYSTEM

MANUAL

IDLING SPEED(IN NEUTRAL)

1000+_50

TRIM METHOD

MANUAL

IGNITION SYSTEM

CDI

CONTROL SYSTEM

TILLER

GEAR POSITIONS

Forward-neutral-reverse

PROPELLER(in)

13-1/8*13"G

Integral fuel tank capacity(L)

Separate fuel tank capacity(L)

24

WEIGHT(KG)

70/103kg

Fuel :Oil RATIO

50:1

PACKED CASE SIZE(cm)

138*87*55

CONTAINER LOADING20/40/40HQ)

38/82/98
