Wheel Aligner

Wheel Aligner photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Seoul, South Korea
Brand Name:
KOENG
Model Number:
KWA 200
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Seoul, South Korea
Brand Name KOENG
Model Number KWA 200

Specifications

- Built-in infrared filter of fixed sensor module.
- Diagnosis and shecking of a suspension, measurement of a ride height.

[Feature]



01. Built-in infrared filter of fixed sensor module.



02. Diagnosis and shecking of a suspension, measurement of a ride height.



03. Built-in program for preliminary checking and analyzing a vehicle



04. Quickly handle by lifting a vehicle when adjusting caster and camber



05. capability of suspension body diagnostics(axle offset, side offset, difference between axles, track, setting back of front and rear wheels)



06. Use of a sensor for accurate compensation of position when runout.



07. use of plus monitor for convenience of control(optional)



08. self diagnostics alarming the use and failure of devices.



09. advanced wheel alignment system to measure car state at the angle of 360



Wheel aligner





[Specification]



model

KWA200
(Passenger car and light truck)

control system
Operating computer intel Pentium4
measurement method 4Head infrared-8sensor
operating system windows OS
output type deskjet printer
wheel size

10"-18" standard

20/22 inch Adapter-option

presicion accuracy

Setback 0.02 degree

Toe 0.02 degree

Caster 0.05 degree

Camber 0.02 degree

measuring range

Setback2 degree

Total toe : 50mm

Caster : 18 degree

S.A.I 18 degree

camber 8 degree

Thrust angle 2 degree

power supply 220v 10%, 50-60Hz
MAX.input power 250w
type of data transfe 4HEAD cable mode
size of main body 710(L) x 680(W)X 1200(H)
