Tactical Portable Two Way Radio From China TD-V58

Tactical Portable Two Way Radio From China TD-V58 thumbnail-1
Tactical Portable Two Way Radio From China TD-V58 photo-1
US$ 10 - 45 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
TID
Model Number:
TD-V58
Contact Supplier Request Quote Chat Now
Guangzhou Tiger Electron Science & Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou Xiamen Hongkong Dubai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name TID
Model Number TD-V58
Type Handheld
Dimensions 98.3*57*28mm
Frequency Range 136-174MHz 400-470MHz
Storage Channel 128
Talk Range 3-5KM

Specifications

tactical portable two way radio from China
1.1200mAh Li-ion battery
2.51CTCSS/214DCS
3.Auto Power-saving
3.DTMF/ 2TON

tactical portable two way radio from China TD-V58


Main Features

Two way radio voice Annunciaion :128 channels by voice annunciation

Two way radio battery capacity: 1200mAh Li-ion Battery

Two way radio voice compander / scrambler

Two way radio wide / narrow band selectable

Two way radio PTT ID

Two way radio Built-iin FM Radio Feature

Time-out timer(TOT)

51 CTCSS / 214CDCSS Encod Decode

1750HZ tone

1). Specification of Profesional FM transceiver two way radio intercom ( TD-V58)

1). Frequency Range

VHF:136-174Mhz ,UHF:400-470MHz ,450-520MHz
2). Channel Capacity 128
3). Channel Spacing 12.5 / 25.0KHz
4). Operation Voltage DC7.4V Li-ion
5). Battery Capacity 1200mAh(Li-ion)
6). Battery life(5-5-90 Duty cycle) about 10 hours
7).Frequency stability ±2.5ppm
8).Operating Temperature -20~+60 °c
9). Antenna Impedance 50 Ω
10). Dimension(H*W*D)(Without Antenna) 98.3*57.7*28mm
11). Weight(With Antenna & Battery) 220g

2).Accessories


tactical portable two way radio from China TD-V58

3).Transmitter

1). RF power output UHF:4.0W/1.0W ,VHF:5.0W/1.0W
2). Modulation tpe F3E
3). Spurious and harmonics -36dBm<1GHz ,-30dBm>1GHz
4). FM Noise 40 /45dB
5). Audio Distortion ≤5%
6). Modulation Respose +1 to-3dB

4).Receiver

1). RF sensitivity ≤0.30 /0.20μV
2). Adjacent channel selectivity 60 / 65dB
3). Intermodulation 65dB
4). Spurious response rejection 70dB
5. S/N 40/45dB
6). Audio power output 500mW
7). Audio distortion ≤5%

tactical portable two way radio from China TD-V58tactical portable two way radio from China TD-V58tactical portable two way radio from China TD-V58tactical portable two way radio from China TD-V58tactical portable two way radio from China TD-V58

5). Payment Terms

1. 100% T/T Advance 2. Western Union 3. Sample by paypal

6).Shipping Terms

EX-works Guangzhou/Hongkong/Xiamen/Dubai

7).Shipping Method

The delivery can by air/Sea or by express, for small order we suggest you can consider sent by express like DHL, FedEx, UPS…
