Home > Consumer Electronics > Radio & Cassette Recorders > Baofeng Uv-5r 5w Dual Band Handy Uhf Radio fm Transceiver
Baofeng Uv-5r 5w Dual Band Handy Uhf Radio fm Transceiver
US$ 20 - 23
MOQ: 1 Piece
Key Specifications
Get Latest Price
Type:
AM / FM
Place of Origin:
Fujian, China
Brand Name:
baofeng
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen Gungzhou Dubai Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Baofeng Uv-5r 5w Dual Band Fine Ham Radio TransceiverUS$ 20 - 23MOQ: 1 Piece -
Baofeng Uv-5r 5w Dual Band Walkie Talkie TransceiverUS$ 20 - 24MOQ: 1 Piece
-
Baofeng Uv-5r Dual Band 5w fm TransmitterUS$ 20 - 23MOQ: 1 Piece
-
Baofeng Uv-5r Base Station TransceiverUS$ 20 - 24MOQ: 1 Piece
-
Baofeng Uv-5r Uhf Base Stations Radios Long RangeUS$ 20 - 23MOQ: 1 Piece
Type
AM / FM
Place of Origin
Fujian, China
Brand Name
baofeng
Model Number
uv-5r
Screen
Yes
Function
Other, dual band
Power Supply
Rechargeable Battery Pack
Specifications
baofeng uv-5r 5w dual band handy uhf radio fm transceiver1.Cheapest 5w dual band two way radio
2.128 channels
baofeng uv-5r 5w dual band handy uhf radio fm transceiver
Main Features:
- Large Half Dot Matrix LCD Display
- Tri-Color LCD Illuminaton
- Dual Band dual frequency standby and Display
- 128 Channels, 3 Types Channel scan
- Priority Channel Scan
- 50 CTCSS/214DCS Encode &Decode And 1 Group User Defined CTCSS/DCS
- 8 Groups of Voice Scrambler
- Voice Compandor
- High/ Low Power Switchable
- DTMF, MSK Signaling
- Selective Call, Group Call
- Remote Kill, Group Call
- Remote Kill, Stun&Activate
- Programmable 25kHz/12.5kHz Channel Spacing
- Voice Operated Transmit VOX
- Squelch Tail Elimination
- Time Out Timer
- Crystal Audio FM Radio
Baofeng UV-5R Two Way Radio Speciation:
| Specifications | |
| Frequency Range | 136~174MHz / 400~470MHz |
| Channel Capacity | 48 |
| Operating Voltage | 7.4V LI-ION |
| Working temperature | -20°C~ 60°C |
| Frequency Stability | ±2.5ppm |
| Dimension(Height×length×width) | 117×52×33mm |
| Channel Spacing | 12.5/25.0 KHz |
| weight | 245g |
| Transmitter | |
| Power output | LO:1W HI: <4W |
| Modulation type | F3E |
| Spurious and Harmonics | 60dB |
| FM Noise | 40dB |
| Audio Distortion | ≤5% |
| Modulation limiting | ±2.5/5.0KHz |
| Audio response | ±3 dB |
| Receiver | |
| Sensitivity | ≤0.30/0.20uV |
| Selectivity | 65dB |
| Intermodulation | 65dB |
| Spurious Response Rejection | 65dB |
| S/N | 45dB |
| Audio Power Output | 700mW |
| Audio Distortion | ≤5% |
