Help CenterBitcoin & Litecoin Mining Power Supply APW3-12-1600-B2 1600W S7/S5/S4/S4+ 12V Power Supply AntMiner PSU Series With 12PCS 6pin
Related Products
-
2016 New Antminer APW3-12-1600-B2 1600w S5/S5+/S7 Psu Power Supply BITMAIN AntMiner APW3-12-1600 PSU SeriesUS$ 118 - 168MOQ: 1 Piece -
2016 New Design Portable Smart Universal Wireless Phone Charger, Factory Supply Directly Wireless ChargerUS$ 2.38 - 3MOQ: 20 Pieces
-
10000mAh Solar Power Bank Dual USB Portable External Battery Charger For Mobile Factory WholesaleUS$ 7.42 - 14.22MOQ: 50 Pieces
-
BITMAIN AntMiner APW3-12-1600 PSU for S7 Series Power Supply for Bitcoin Miner,Bitcoin Miner PSU 1600W for Antminer S7US$ 140 - 185MOQ: 5 Pieces
-
1600W PSU Power Supply For Bitcoin Miner Antminer S7 Ant Miner Newest Batch APW3-12-1600 for S5 S7US$ 118 - 168MOQ: 1 Piece
APW3-12-1600 PSU 1600W power supply for bitcoin miner
Power supply for S5 S7 bitcoin miner
The APW3-12-1600 Series AC-DC PSU is specifically designed with mining operations in mind, and combines high conversion efficiency and a strong dynamic performance into a power dense package. It also features short circuit, overload, overheat, low voltage and overload protections.
This PSU includes several features which make it optimal for cryptocurrency mining operations, including:
1) The air flow direction runs from the AC input to the DC output, which is the same configuration as most miners. This proves beneficial for those with large-scale mining operations where heat management is a major consideration.
2) The PCB uses a conformal coating to prevent damage from high voltage spark discharges on MOS pins, or near high-pressure solder joints when external conductive particles or dust enter the PSU.
3) The APW3-12-1600 can work stably in environments with a 50°C ambient temperature. If temperatures exceed 50°C, the PSU should be underclocked (refer to Max Load vs. Ambient Temperature Graph in the user guide for details). Considering the high temperature in mining operations, all internal components are selected with a standard of 105°C, so the APW3-12-1600 has a much longer lifespan than a general use PSU under similar high temperatures.
4) The APW3-12-1600-B2 uses a PCI-E connector which is compatible with currently available ATX PSUs, as well as most bitcoin mining machines.One APW3-12-1600 is enough to power two AntMiner S5s at the same time.
Note:
1. The PSU cannot be used in countries with a mains power voltage lower than 205V. The PSU will not start below this voltage.
2. Electronic Parameters:
Output :
DC Voltage : 12V
Rated Current : 133A
Rated Power: 1600W
Ripple & Noise : <1%
Voltage Regulation : <2%
Source Regulation : <1%
Load Regulation : <1%
Setup, Rise Time : <5S
Power off Protection Trip Time : >10mS
Interface Type : 6 pairs of 6 pin PCI-E connectors. 450mm length for each PCI-E cable
Input
Voltage Range : 176-264V AC
Starting Voltage : 200-205V AC
Frequency Range : 47-63Hz
Power Factor : >0.95 (full load)
Leakage Current : <1.5mA (220V 50Hz)
Overheat Protection : Yes
Weight : 2.3kg
Fan Size : 40mm*40mm*28mm
