Large Format uv Flatbed Printer
US$ 20,000 - 40,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
A3 Size Small Size uv Flatbed PrinterUS$ 3,000 - 7,000MOQ: 1 Piece -
A2 Size uv Flatbed PrinterUS$ 3,000 - 7,000MOQ: 1 Piece
-
Roll and Flatbed Hybrid uv PrinterUS$ 8,000 - 12,000MOQ: 1 Piece
-
A2 Size Directly T-shirt Printing MachineUS$ 4,000 - 8,000MOQ: 1 Piece
-
Large Format UV PrinterUS$ 1 - 20,000MOQ: 1 Piece
Condition
New
Plate Type
Flatbed Printer
Place of Origin
Guangdong, China
Brand Name
Yinghe
Model Number
YH-2030HL
Usage
Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer
Automatic Grade
Automatic
Voltage
220V
Gross Power
60HZ
Dimensions(L*W*H)
4.25m x1.95m x1.68m
Weight
1000KG
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
| FEATURES | |||
| 1,UV light curing, the screen fine, convenient and quick. | |||
| 2,Print on flexible and rigid media,Including PE,PP,ABS,PMMA,PS,PU,metal,ceranic tile and glass,etc | |||
| 3,Screen color fastness is good, outdoor 3-year non-fading | |||
| 4,Moving parts is the raster, resolution is high; negative pressure for the ink, | |||
| constant temperature technology, suitable for a wider geographical temperature changes. | |||
| 5,Reflects the many advantages of digital printing, no plate-making, computer control technology, | |||
| easy to learn, without professional knowledge, easy to spread | |||
| 6,The key technology for the United States imports, stable performance, low energy consumption. | |||
| Technical parameters | |||
| Model | YH - 2030HL | ||
| Media fixation methods | Vacuum or Common platform (Optional) | ||
| Printing size | 2000X3000(mm) | ||
| Media thickness | 1---70mm(Special requests can be made to order) | ||
| Printhead type | Konica KM512 14pl | ||
| Printhead control | Nozzle temperature and voltage controlled by software | ||
| Drying system | UV Lamp (Integration Technology) | ||
| Rip software | Photoprint DX10.0 VERSION | ||
| (Windows 2000,Windows XP Pro Sp2) | |||
| Media types | Metal,Glass,Woodboard,Aluminum plastic board,PMMA,Ceramic tile,Textile | ||
| Self-adhesive paste,Cystose,Corrugated sheet,Plastic,Wallpapers,Papers | |||
| Ink types | Environmentally-friendly UV curable Inks | ||
| Special ink | UV White ink or UV transparent varnish, | ||
| have been pre-split special ink in tank | |||
| Interface | USB | ||
| Electrical Environment | One-way exchange of 220V,50/60Hz | ||
| Color control | Comply with international ICC standards, | ||
| function of curve and density adjustment | |||
| Image formats | TIFF,JPEG,EPS,PDF ect. | ||
| Printhead quantity | 4 | 6 | 8 |
| Printing speed(max) | 360X1440dpi 12m2/h | 360X1440dpi 12m2/h | 360X1440dpi 24m2/h |
| 720X720dpi 10m2/h | 720X720dpi 10m2/h | 720X720dpi 20m2/h | |
| 720X1440dpi 8m2/h | 720X1440dpi 8m2/h | 2880x720 DPI 16m2/h | |
| Colors | C,M,Y,K,LC,LM,White(W),Varnish(Clr) | ||
| Environment request | Best temperature:18-25℃,relative humidity:40-70% | ||
| Dimension | 4.25m x1.95m x1.68m | ||
| Special sizes can be ordered | |||
| Gross Weight | 900kg | ||
We have many kinds of uv flatbed printer,welcome to visit our showroom
