XTOOL PS2 Heavy Duty Scan Tool

Specifications

1.diesel diagnosis tool
2.one year warranty
3.2 years free update
4.support bluetooth wireless communication

Xtool Heavy Duty Scan Tool



PS2 Heavy Duty is a professional diagnostic system with strong and stable diagnostic functions. It covers major American, European and Asian heavy duty vehicles. With a large touch screen and simple body, it is easy to operate.







Vehicles Coverage

European: ASTRA, DAF, ERF, VOLVO, SCANIA, MAN, IVECO, MERCEDES BENZ, RENAULT

Asian: ISUZU, HINO, FUSO, HYUNDAI, KIA, UD, TOYOTA

American: CAT, CUMMINS, ALLISON, DETROIT, FREIGHTLINER, INTERNATIONAL, KENWORTH, MACK







Features

• 400 MHz  ARM chip provides you with a fast diagnostics operation system
• Advanced and comprehensive diagnostic software platform provides you with a fast and stable application system
• 8-inch true color touch screen offers you a comfortable operation
• Built-in high-performance overvoltage protection circuit provides you with high product reliability
• Storage and playback of test data and pictures are available
• Alternative with Bluetooth wireless and wired communication mode offers you flexibility
• Unique VCI self-test function
• 2 year online update for free & 1 year warranty



Functions

Basic Functions:

• Retrieves ECU information
• Reads/clears trouble code
• Views data stream/freeze frame data
• Actuator test

Advanced Functions:

• Reads/rewrites the fuel injector QR code
• Functional tests

It can do functional tests such as Cylinder compression, Cylinder balance, Cylinder cut off, Control unit adaptations, high pressure test, and compression test.

(Note: Advanced functions vary by manufacturer, year and model. The actual advanced functions supported please refer to the function list.)



Technical Specification

Operating System	WINCE 5.0
CPU	SAMSUNG 32-bit processor 400MHZ
SDRAM	64M
Flash Memory	64M
External Memory	large capacity SD card is available
Display	8-inch 800x600 touch screen with LED backlight
Communication	wireless Bluetooth/wired communication
Input Voltage	DC 12V/24V
Battery	rechargeable battery 3500m/Ah
Printer	mini high-speed thermal printer
Operating Temperature	0 to 50ºC (32 to 122ºF)
Storage Temperature	-10 to 70 ºC (14 to 158 ºF)
Relative Humidity	<90%
Dimension	305.2 mm ×215.2 mm ×85mm
Weight	9.5KG





Accessories

SD card, VCI, touch pen, testing adapters, group of lines, user manual, suitcase
