Optical Thin-films Deposition Machine(Electron Gun)
Ⅰ.MAIN TECHNICAL PARAMETERS
MODEL: OEC-l350 / USED: Optical Lens |
Chamber Inner Size: Diameter1350×H1500mm |
|
Vertical Front-Opening door Vacuum Chamber Dome: 2 sets – 3 section Heating: Halogen lamp:6KV |
Chamber Material:SUS 304 Stainless Steel |
|
Diffusion Pump:KT-630 (2 sets) 24” Vacuum System: Roots Pump:ZJY-600(1 set) Preceding Mechanical Pump:H-150(1 set) Holding Pump:2X-30(1 set) Note**(When the machine stops, the pump work 2 hours or so, to protect the vacuum and the whole system,it also mechanical pump) |
Ion Source: 1 set Model: CDNY-07LZ/2KW, Produced by Chendu Nanyi |
Electronic Gun: model:JYK-HZ08 8/10KW |
Quartz Crystal Control: SQC -310 Produced USAUNINFICON |
Polycold Machine:Model:TH-135-15P, produce by Beijing Tiandi Jingyi Technology Co., Ltd. |
|
Vacuum Gauge: ZDF (Pirani-2ea, penning 1-ea), produced Chengdou ZhengHua |
Ultimate Vacuum: 6.0×10-4Pa |
Working Vacuum: 2.0×10-2Pa |
Static Leakage Rate: 0.67Pa/h |
Cooling Mode: water circulation cooling |
|
2 sets of control cabinets Control Mode: touch Screen of 12 inches, color screen PLC programmable from Mitsubishi of Japan. |
|
Alarm and Protection Alarm for water shortage, over current, and the over voltage and broken circuit protection, Perform the corresponding Measures and the function of electric interlock.
|
|
Other Parameters: Water Pressure: > 0.2 to 6 Mpa, 80 L/Min Water Temperature:≤22ºC Air Pressure: 0.4 to 0.6 Mpa Power Supply: 220/380V,60Hz–60KV/50HZ
|
|
Manual for each parts & components must have a manual of operation and maintenance version in English.
|
|
Spare parts with the machine must supply the main necessary to consumable of pieces that is change when is necessary when the machine is on operation.
|
Tool Box: A complete set of tool to make maintenance |
Ⅱ.INSTRUCTION FOR CR-39 LENS COATING
(1) For such coatings, the lens can coating 4 to 5 kinds, the maximum coatings can up to 10 layers and coating on the two sides(front and back side), its thickness about 4-5um(0.004-0.005mm). Each layers have its functions, such as hardening coatings also named wear resistance coatings, its function is improve the surface hardness and abrasion resistance ability for the lens to prolong the lifetime for the lens. Anti-reflective coatings also named antireflection coatings, it can effectively reduce the reflection of light and improve the light transmittance and clarity vision. Anti-fouling coatings also named hydrophobic coatings, it makes the surface of lens will not easily have the adhesion of dust
