swimming goggles polycarbonate lens coating machine
Application: glasses for ophthalmic , camera lens, and eyeglasses.
polycarbonate lens coating machine Technology Specifications
Ⅰ,MAIN TECHNICAL PARAMETERS
MODEL: OEC-l350 / USED: Optical Lens |
Chamber Inner Size: Diameter1350×H1500mm |
|
Vertical Front-Opening door Vacuum Chamber Dome: 2 sets – 3 section Heating: Halogen lamp:6KV |
Chamber Material:SUS 304 Stainless Steel |
|
Diffusion Pump:KT-630 (2 sets) 24” Vacuum System: Roots Pump:ZJY-600(1 set) Preceding Mechanical Pump:H-150(1 set) Holding Pump:2X-30(1 set) Note**(When the machine stops, the pump work 2 hours or so, to protect the vacuum and the whole system,it also mechanical pump) |
Ion Source: 1 set Model: CDNY-07LZ/2KW, Produced by Chendu Nanyi |
Electronic Gun: model:JYK-HZ08 8/10KW |
Quartz Crystal Control: SQC -310 Produced USAUNINFICON |
Polycold Machine:Model:TH-135-12P, produce by Beijing Tiandi Jingyi Technology Co., Ltd. |
|
Vacuum Gauge: ZDF (Pirani-2ea, penning 1-ea), produced Chengdou ZhengHua |
Ultimate Vacuum: 6.0×10-4Pa |
Working Vacuum: 2.0×10-2Pa |
Static Leakage Rate: 0.67Pa/h |
Cooling Mode: water circulation cooling |
|
2 sets of control cabinets Control Mode: touch Screen of 12 inches, color screen PLC programmable from Mitsubishi of Japan. |
|
Alarm and Protection Alarm for water shortage, over current, and the over voltage and broken circuit protection, Perform the corresponding Measures and the function of electric interlock.
|
|
Other Parameters: Water Pressure: > 0.2 to 6 Mpa, 80 L/Min Water Temperature:≤22ºC Air Pressure: 0.4 to 0.6 Mpa Power Supply: 220/380V,60Hz–60KV
|
|
Manual for each parts & components must have a manual of operation and maintenance version in English.
|
|
Spare parts with the machine must supply the main necessary to consumable of pieces that is change when is necessary when the machine is on operation.
|
Tool Box: A complete set of tool to make maintenance |
Lens coating machine samples
