vacuum evaporators combination with magnetron sputtering coating machine
- 15 Set / Sets per Month
- Shanghai
- T/T
- Feiyide Mini Manual Silver Barrel Electroplating Production Line
- Feiyide electroplating rectifier for chrome zinc plating
- Feiyide Electroplating Equipment Zinc Chrome Screw Plating Equipment
- Feiyide Titanium anode basket,electroplating machine ,positive pole device
- Feiyide Nickel Plating Equipment Electroplating Machine for Nuts Bolts
- Feiyide Continuous Gold Plating Brushing Sets
Product Details
Condition: | New | Place of Origin: | Shanghai, China | Brand Name: | Vakia |
Model Number: | Optional | Voltage: | 380V | Power(W): | 40KW |
Dimension(L*W*H): | 3x4x2m | Weight: | 2000-4000kg | Certification: | CE |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
vacuum evaporators combination with magnetron sputtering coating machine
1. Summary Technical Parameters
Model Function | VAKIA -SRC -900 | VAKIA -SRC -1000 | VAKIA -SRC -1200 | VAKIA -SRC -1400 | VAKIA -SRC -1500 | VAKIA -SRC -1800 |
Vacuum Chamber Inner Size | 900 *H1100 mm | 1000 *H1200 mm | 1200 *H1500 mm | 1400 *H1800 mm | 1500 *H1900 mm | 1800 *H2000 mm |
Power Supply Type | Resistance Evaporation Power Supply,Ion bombardment Power Supply,Filament power supply,Pulse Bias Power Supply,Direct Current magnetron power Supply,Medium Frequency Magnetron Power Supply | |||||
Structure of Vacuum Chamber | Vertical Double Door,Vertical Single Door,Horizontal Single Door,Back Vacuum Acquisition System | |||||
Material of Vacuum Chamber | Superior Stainless Steel Chamber | |||||
Ultimate Vacuum | 8.0×10-4Pa | |||||
Pump-out Time(no-load) | From air to 5.0×10-2Pa≤8min | |||||
Vacuum Acquisition System | Diffusion pump or molecular pump+Roots pump+Mechanical pump+Holding pump(The specification can be selected according customer’s demand) | |||||
Coating Style | Evaporation coating+magnetron sputtering coating | |||||
Kinds of Film | metal film,semi-transparent film,Non conductive vacuum metallization film Electromagnetic Interference film,Dielectric film | |||||
The Style of Magnetron target | Rectangle magnetron target,cylindrical magnetron target,twin magnetron dual target | |||||
Power of Magnetron bias power supply and the number of magnetron target | The appropriate equipment is selected according to demanders’requirements and different techniques | |||||
Work Piece Rotation maximum valid diameter | 6 axis 260mm | 6 axis280mm | 6 axis 360mm 8 axis 280mm | 6 axis 420mm 8 axis 350mm | 6 axis 460mm 8 axis 380mm | 6 axis 560mm 8 axis 460mm |
Evaporation electrode | Standard configure 2 pair | |||||
Evaporation Power | 15KW | 15KW | 20KW | 25 KW | 30KW | 35KW |
Total Power | 50KW | 50KW | 65KW | 85 KW | 100KW | 135KW |
Process Gas | Two or three process gas flow control and display system,select automatic filling system | |||||
Cooling System | Water-cooling circulatory system,cooling water tower or industrial cooling water machine is also needed(which are supplied by demander) | |||||
Work Piece Rotating Stand and Rotating Style | Planetary revolution-autorotation and frequency conversion speed regulation (controlled and adjustable) | |||||
Control Mode | Automatic and Manual operation modes integrated,touch screen,PLC or computer control | |||||
Alarm and Protection | It has the function of alarm in case of the existence of abnormal conditions like water failure or over-current or over-voltage disconnection.It can carries out protective measurements and has the function of interlock. | |||||
Cover Area | W3m×L3m | W3m×L3m | W3.5m×L4m | W5m×L5m | W6m×L6m | W6m×L8m |
Other Technical Parameters | Water pressure≥0.2MPa,water temperature≤25 centigrade,gas pressure0.5-0.8MPa | |||||
Remark | Designed flexible and select the appropriate equipment according to demanders’requirements |
2. Summary Description
VAKIA-SRC evaporation combination with magnetron sputtering vacuum coater combine vacuum evaporation technology with magnetron sputtering, realizing multi-functional coating demand. This machine equipped with high efficient resistance heating evaporation device and advanced cylindrical or plane magnetron sputtering device. This composite machine can acquire a variety of film with different performance. It has a wide range of applications for such industries as plasticceramic and metal products with the following colors as goldensilverblackorchidredpurplegrey and rainbow colors available.
3. Coated Samples
